16Ch FULL D1 Network Video Server with TWO SATA

Model

NVS404HF-A

NVS0804HF-A

NVS1604HF-A

System

Main Processor

Dual-core embedded processor NVS1604HF-A

Operating System

Embedded LINUX

Video

Input

4 channel, BNC

8 channel, BNC

16 channel, BNC

Output

1HDMI, 1VGA, 1TV, 1Spot BNC(1.0Vp-p, 75)

Standards

PAL(625Line, 50f/s), NTSC

Audio

Input

4 channel

8 channel

4 channel

Output

1 channel

Two-way Talk

1 channel

Display

Resolution

1920×1080, 1280×1024, 1280×720, 1024×768, 800×600

Display Split

1

1/4

1/4/16

Privacy Masking

4 rectangular zones (each camera)

Recording

Video/Audio Compression

H.264 / G.711

Resolution

D1/CIF/QCIF/VGA/QVGA

Record
Rate

Mainstream

D1/BCIF/CIF/QCIF(1~25/30fps)

Extra stream

CIF/QCIF

Digital Watermark

Support

Video Detection & Alarm

Trigger Events

Recording, PTZ, Tour, Snapshot, Alarm, Video Push, Email, FTP, Spot,
Buzzer & Screen Tips

Video Detection

Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank

Alarm Input

4 channel

8 channel

16 channel

Relay Output

3 channel

Playback & Backup

Search Mode

Time/Date, Alarm, Motion Detection & Exact search (accurate to second)

Playback Functions

Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom

Storage

Internal HDD

2 SATA

Backup Mode

USB Device / Network

Network

Ethernet

RJ-45 (10/100/1000M)

Wireless

3G

EVDO(CDMA1X)/WCDMA and other 3G network (model–E/-C only)

Wi-Fi

802.11b/802311g (model –W only)

Network Functions

TCP/IP, PPPOE,DDNS, FTP, IP Filter, DNS, SMTP, NTP, DHCP

Auxiliary Interface

USB

1 Port

RS232

PC communication

RS485

PTZ control

General

Power Supply

DC12V / 3A

Power Consumption

20W (Exclude HDD)

Working Environment

-10°C ~+50°C / 10%~90% / 86kpa~106kpa

Dimension(W×D×H)

440mm x 300mm x 42.1mm

Weight

2.5Kg
