dahua professional h.264 wireless 3g network video server support 2 SATA

Specifications

dahua network video server for cctv system
3g wifi cctv nvs
h.264 realtime full d1
audio alarm input
1 SATA recording

professional h.264 wireless wifi 3g network video server with 2 SATA dahua



Features:
> 4/8/16 channel video and audio inputs
> H.264 video compression and JPEG image capture
> Full channel@D1(4CIF) realtime encoding
> 3D intelligent positioning with PTZ dome camera
> 3G (Model –E/-C only), Wi-Fi (Model –W only), 2SATA, 1USB
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS



Model		KDW-DS404DT			KDW-DS408DT		KDW-DS416DT
System
Main Processor		Dual-core embedded processor
Operating System		Embedded LINUX
Video
Input		4 channel, BNC			8 channel, BNC		16 channel, BNC
Output		1HDMI, 1VGA, 1TV, 1Spot BNC(1.0Vp-p, 75)
Standards		PAL(625Line, 50f/s), NTSC
Audio
Input		4 channel			8 channel		4 channel
Output		1 channel
Two-way Talk		1 channel
Display
Resolution		1920×1080, 1280×1024, 1280×720, 1024×768, 800×600
Display Split		1		1/4				1/4/16
Privacy Masking		4 rectangular zones (each camera)
Recording
Video/Audio Compression		H.264 / G.711
Resolution		D1/CIF/QCIF/VGA/QVGA
Record	Mainstream	D1/BCIF/CIF/QCIF(1~25/30fps)
Rate	Extra stream	CIF/QCIF
Digital Watermark		Support
Video Detection & Alarm
Trigger Events		Recording, PTZ, Tour, Snapshot, Alarm, Video Push, Email, FTP, Spot,
		Buzzer & Screen Tips
Video Detection		Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input		4 channel	8 channel			16 channel
Relay Output		3 channel
Playback & Backup
Search Mode		Time/Date, Alarm, Motion Detection & Exact search (accurate to second)
Playback Functions		Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Storage
Internal HDD		2 SATA
Backup Mode		USB Device / Network
Network
Ethernet		RJ-45 (10/100/1000M)
Wireless		EVDO(CDMA1X)/WCDMA and other 3G network (model–E/-C only)
		802.11b/802311g (model –W only)
Network Functions		TCP/IP, PPPOE,DDNS, FTP, IP Filter, DNS, SMTP, NTP, DHCP
Auxiliary Interface
USB		1 Port
RS232		PC communication
RS485		PTZ control
General
Power Supply		DC12V / 3A
Power Consumption		20W (Exclude HDD)
Working Environment		-10°C ~+50°C / 10%~90% / 86kpa~106kpa
Dimension(W×D×H)		440mm x 300mm x 42.1mm
Weight		2.5Kg
