Specifications
1.Compact structure, the filtering effect is good2.Continuous operating
3.Equipment is not easy jammed
HHY miscella filter
HHY miscella filter is a kind of filtered mechanical equipment which is applied in crude oil.
Wet dust content is reduced greatly after filtering. The oil evaporation effect is improved. This equipment can improve the quality of crude oil and the by-products.
The features of this equipment
1. Compact structure. The filtering effect is good.
2. This filter can achieve continuous operation. The equipment is not easy jammed. It is convenient for dismantling and reduces the labor strength.
3. It can improve the quality of crude oil and provide the prerequisite for extracting the phospholipids.
Main specification and technical parameter
MODEL |
HHY15 |
HHY20 |
HHY25 |
HHY30 |
HHY40 |
HHY60 |
|
LEACHING PRODUCTIVITY (t/d) |
30 |
50-100 |
100-150 |
200-300 |
400-600 |
600-800 |
POWER(kw) |
2.2 explosion-proof |
2.2 explosion-proof |
2.2 explosion-proof |
3.0 explosion-proof |
4.0 explosion-proof |
4 explosion-proof.0 |
SPINDLE SPEED (rpm) |
10 |
10 |
10 |
10 |
10 |
10 |
SLAG PUMP TYPE |
32ZW-10-20 |
40ZW-15-20 |
40ZW-15-20 |
50ZW-15-20 |
65ZW-30-20 |
65ZW-30-20 |
DIMENDIONS |
2430*1800*1800 |
2430*2000*2000 |
2430*2000*2000 |
2790*2000*2000 |
2830*2200*2200 |
2830*2260*2200 |
FILTER AREA |
15 |
20 |
25 |
30 |
40 |
60 |
WEIGHT(kg) |
1750 |
2080 |
2450 |
2450 |
3560 |
4000 |
