Specifications
1.die board cutting2.CE certificate
3.USB control,
4.chiller cooled system
5.stepper motor
Die Acrylic Board Cutting Laser G1212
Mian Features :
1.Stable machine design, convenient for operation
2.Laser path fixed ( laser head fixed, cutting material plywood moving)
3.Double direction imported high precision ball-screw transmission
4.Low consumption of voltage, about three kilowatt-hour only
5.High series industrial water chiller CW-6000, America lens
6.High strength of machine bed, long-year working stable
7.No need of assistant gas during cutting, Air only
8.TSD Laser software, PC control.
9.Easy to adjust laser focus, operate machine easy after training well.
Parameter
Processing scale |
1200x1200mm |
Machine weight |
1300kgs |
Laser type |
CO2 Sealed laser tube |
Laser power |
300W - 400W double heads |
Driving motor |
Higher grade stepper / Japan Panasonic Servo Motor |
Cutting depth |
14mm-16mm-18mm plywood |
Cutting precision |
±0.05MM |
Re-position accuracy |
≤0.03mm |
USB port connection |
Yes |
Operating temperature |
0-45°C |
Mould knife thickness |
0.45mm, 0.71mm,1.05mm…etc. controllable |
Cutting speed |
23-30meters/hour 18-20mm plywood |
Protective gas |
Dry and oil-free air |
Power supply |
single-phase electricity 220V±5% 50HZ 10A |
Numerical control panel |
LCD screen, light-touched key-press |
Software supported |
CorelDraw, AutoCAD, Photo Shop |
Graphic format support |
PLT,DXF,BMP,JPG,GIF,PGN,TIF |
EMS memory |
attached 64MB memory, can work under off-line condition |
Application |
Plywood, MDF board, acrylic board. |
Laser tube guarantee |
Guarantee 6months,10000 hours life span for laser tube |
Assistant equipments |
Air Dryer, industrial chiller, Exhaust Fan, Computer System |
Recommend spare parts |
Laser Tube and America Lens |
Application :
1.can make box type design samples based on the actual paper material .
2.printing ,knife mold factory ,plastic plants ,die cutting plant ,proofing plant ,carton plant ,packing plant .
3.printing factory knife templated ,cutting board production .
Samples:
