Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Cutting Machine > Hobby Metal Laser Cutting Machine G-150300DT

Hobby Metal Laser Cutting Machine G-150300DT

Name: Hobby Metal Laser Cutting Machine G-150300DT
Brand: Grace
SKU: 110052679
Availability: InStock

Hobby Metal Laser Cutting Machine G-150300DT thumbnail-1

Hobby Metal Laser Cutting Machine G-150300DT photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

Grace

Model Number:

G-150300DT

Contact Supplier Request Quote Chat Now

Jinan Grace Machinery Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name Grace

Model Number G-150300DT

Rated Power 650w

Weight 3000KG

Specifications

1)Gantry style design.
2)Laser cutting is no touch process
3)cutting edge is smooth
4)LCD display screen offline control

Laser Cutting Machine G-150300DT

*SPECIFICATONS*
ITEM		TECHNICAL SPECIFICATIONS
MACHINE
Model Name		G-150300DT
Travel Method		stationary table , Gantry style
Moving system		Servo motor drive ball screw
Guide		Dual linear guide
Control Method		X, Y,Z axis motorized controlled
Travel Amount	X-axis	1500MM
	Y-axis	3000MM
	Z-axis	25mm (it's standard) customized by requirements
Feed Rate	X-axis	2500mm/sP²^P
	Y-axis	2000mm/sP²^P
rapid speed	X-axis	800mm/s
	Y-axis	600mm/s
Maximum Worksheet Loading Capacity		700kg
Machine weight		3000kg
Repeatability Positioning Accuracy		0.01mm
Drive Feed Method		position control / AC servo motor
Machine Table Height		900mm
Cutting bed		Sawtooth metal strip bed
Focus type		Automatic following focus
Power Supply ( only for machine)		380V 50/60HZ
Power consuption		30KW

LASER OSCILLATOR
Laser Oscillation Method		Lamp pump YAG
Laser power		500W/650W
Stability		±3%
Frequency		1-300HZ
Wavelength		1064nm
Single pulse energy		125J
Pulse width		0.3-10ms
Cooling mode		Close loop laser chiller cooling

CNC CONTROL UNIT
CNC Unit		Yaskawa AC servo motor
CNC Control Method		semi-close loop control
Control Functions		X, Ycontrolled (simultaneously controlled)
Input Method		USB, Net port, memory stick
Least Input Increment		0.002mm
Minimum Position detection Accuracy		0.002mm
Program Storage Capacity		128M flash memory in machine
Operating Modes		Windows xp support
Display Function	5 inchi display	Cutting process Position information Parameters design preview

Software
cutting software		Golden Laser self developed software
Nesting software		Golden Laser self developed software
Support format		DXF,DWG,PLT,AI,DST,GLD
