Good price and high quality Glass/Bamboo/Acrylic Laser Engraving Machine

FOB Price

USD $3,000 - $4,000 / Set

1 Set(Min.Order)

Supply Ability 50 Set / Sets per Month
Port Qingdao
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Laser Type:	CO2	Engraving Area:	600*900 mm
Engraving Speed:	0-1000 mm/s	CNC or Not:	Yes	Cooling Mode:	Water Cooling
Applicable Material:	Acrylic, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood	Graphic Format Supported:	AI, BMP, DST, DWG, DXF, DXP, LAS, PLT, Other, AI, BMP, DST, DWG, DXF, DXP, LAS, PLT, JPG	Place of Origin:	Shandong, China
Brand Name:	Shendaio	Model Number:	SD-6090	Certification:	CE, Other, CE, FDA
After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Specifications

laser cutting and engraving machine.
1.High quality and high precision.
2.Fast speed and flexible operation.
3.CE FDA

Good price and high quality Glass/Bamboo/Acrylic Laser Engraving Machine

Features:

1.It has big power and a high stability laser tube, imported lens and long lifespan mirror.

2.It offers optimization of mechanical and electrical design.

3.It is used imported linear rail and is more precision and durable.

4.It owns functions of restoring from power off, continuation on break point.

Product Description

Parameters:

Model	SD6090 Laser Engraving&Cutting machine
Standard Laser power	60w(80w/100w)
Laser type	sealed CO2 laser tube
Working area(mm)	600x900
Cutting depth	Acrylic 0-20mm, depending on materials
Engraving speed	0-75000mm/min
Cutting speed	0-60000mm/min
Location precision	≤0.01mm
Minimum forming character	Chinese:2x2mm English: 1x 1mm
Power supply	220V±10% 50HZ or 110V±10% 60HZ
Software supported	BMP, CIF, JPEG, TGA, TIFF, PLT, AI, DXF, DST (TIANDAO Embroidery Software), DWG, CDR, etc
Main Graphic format supported	PLT/DXF/BMP/AI (Direct output)
Engraver for Curve surfaces	Rotary clamp is optional and used to engrave on curve surfaces
Cooling mode	Water-cooling and protection system
Max thickness of engraved object	280mm
Laser tube(life hours)	3500-4000hours
Gross power	1200w
Driving system	Stepper motor(x,y,z,axis)
Machine control	Speedy DSP controling
G.W.	280kg
Applications	acrylic, PVC, rubber sheet, plastic, crystal, glass, wood, bamboo, oxhorn, figuline,marble, leather, cloth, double-color board, etc. nonmetal materials
Working environment	Temperature:0-45℃ Humidity:5%-95%
Certificate	CE, FDA
Assistant Equipment:	Red dot pointer Water pump Air pump Exhaust fan Motorized up and down worktable Blade worktable
Optional Spare Parts:	Rotary clamp with roller/clips Water chiller Auto focus Purifier & Filter system Servo motor CCD camera RF laser tube

Applications:

Acrylic, wood, bamboo, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials,etc.

Applicable industries:

1) Advertising industry:
a) Double-colored board carving
b) Organic glass carving and cutting

c) label carving

d) crystal cup carving

    e) Warranty signed carving
2) Carved gifts and crafts industry:
    a) Wood
    b)Bamboo

    c) Ivory
    d) Bone
    e) Leather
    f) paper

3) Packing and printing industry:
    a) Rubbery board
    b) Plastic board
    c) Double-layered board
    d) Model cutting board

4) Leather clothing industry:
    a) Complex characters and pattern carving
    b) Cutting on hypoderm
    c) Synthetic leather
    d) Man-made leather
    e) Cloth

5) Architectural model industry:
a) ABS board cutting
b) Model carving

6) Production totem industry:
a) Appliance signs
b) Anti-fake commodities marking

Optional water cooling:

Our Services

1. 24 hours technical support by e-mail, calling or door-to-door service.

2. English software, user manual and detailed Videos CD.

3. International quality certificate:CE,FDA.

4.12 months for machine warranty and long life span of laser tube.

5. Our technican can offer free training in our workshop.

Packaging & Shipping

Our Package Advantage:
1.Our wooden case is after fumigation treatment.Needn’t timber inspection,saving shipping time.

2.All the spare parts of the machine were covered by some soft materials,mainly using pearl wool.

Avoiding all damages that could happen in the delivery process.Then we’ll covered plastic wrap out it tightly,make sure intact of the covered soft materials,also avoiding Waterproof and rust proof.
3.The outmost is wooden case with fixed formwork.
4.The bottom of the wooden case has firm iron jack,convenient to Handling and transport.

Contact Us

Jinan Shendiao Mechanical Equipment Co., Ltd.: Contact nameShendiao Kong; Phone86-0531-88084966; AddressWest Of Shuipo Village, Wangsheren Street, Licheng District
