SD-4040 Advertising industry Wood MDF Marble Stone Plastic Acrylic Paper Rubber laser engraver
- 40 Set / Sets per Month
- Qingdao
- T/T Credit Card PayPal
-
DANAPR UV Laser Marking Machines F2010
-
1390 large laser engraving machine window cut paper PVC plating film laser cutting machine, cardboard paper engraving machine
-
DANAPR UV Laser Marking Machines F2010 UV laser
-
3D Crystal Laser Engraving Machine
-
DANAPR UV Laser Marking Machines F2005 UV laser
-
DANAPR UV Laser Marking Machines
Product Details
| Condition: | New | Laser Type: | CO2 | Engraving Area: | 400*400mm |
| Engraving Speed: | 1000mm/s | CNC or Not: | Yes | Cooling Mode: | Water Cooling |
| Applicable Material: | Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood | Graphic Format Supported: | AI, DST, DWG, DXP, LAS, PLT | Place of Origin: | Shandong, China |
| Brand Name: | shendiao | Model Number: | sd-4040 | Dimension(L*W*H): | 400*400mm |
| Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Advertising industry, Wood, MDF, Marble, Stone, Plastic, Acrylic, Paper, Rubber laser engraver
Feature:
1.High-speed USB offline control system. on this series ofma chine, framework Integrally designed, working stably,economical and practical type machine widely used. 2.Software completely compatible with AutoCAD.CoreDRAW etc. CAD. CAM and various photo processing software, original photo output directly. For engraved plate printing industry, based on original model, a function of full slope enables the easily-distorted parts such as small words,barcode to become more durable. Its excellent printing effect and printing precision could compare with flexible version, part of them could replace expensive soft resin version. 3.Equipped with high precision linear square guiding rail, with smoke purifier system, little noise, the machine is the best choice of the middle and small size home workshop.
Sepcification:
SD-4040 | ||
Wattage | 40W/50W | |
Laser Source | Sealed CO2 Laser | |
Cooling | Water Cooled | |
Working Area | 400*400mm | |
Dimensions (W x L x H) | 950Tall x 250Deep x 600Wide mm | |
Drive | Closed-loop DC stepper control | |
Maximum Motor Speed | 40 IPS | |
Speed Control | Adjustable from 0~100% | |
Power Control | Adjustable from 0~100% | |
Distance Accuracy | 0.1mm | |
Computer Interface | Standard printer port and USB 2.0** port | |
Operation Voltage | 110V-220V AC | |
Power Consumption | 1000w | |
Graphic format supported | BMP,JPG,GIF,HPGL,NC,PLT,DST,DXF,AI ... | |
Water Chiller | Water Chiller required | |
Air Exhaust System | External exhaust system required |
SAMPLE
Jinan Shendiao Mechanical Equipment Co.,Ltd is known for excellent service and bringing forth laser products that are the best quality of all Chinese laser cutting machines. This equipment can be applied to many kinds of materials, and has many advantages, such as smooth cutting edges, free from polishing, no noise, no dust, faster processing speed, higher precision, less waste and more efficiency. It is the best option for upgrading traditional equipment in various industries.
If custom ordering a machine, the color can also be specified.
