Specifications
Handheld USB Waterproof Endoscope / Borescope / Inspection CameraBrief Description
This Mini USB Inspection Camera use optoelectronic technology to investigate hard-to-reach area. It helps you to diagnose broken part, weld point and released parts easily to save time and increase productivity. You can just plug to capture video in AVI format and snapshot image in BMP format with 640 x 480 VGA resolutions.
It has 4pcs of built-in LED light (with brightness control) on camera head to illuminate the inspection area. The 150 cm (4.9 feets) Flexible Supporting Cable is waterproof with 10 mm diameter camera head so that you can inspect area under water, gaps and holes.
The tool set also comes with accessory hook, magnet and mini mirror to attach to the camera head for picking up small objects (e.g. ring, earring), viewing and hooking to identify the problem conveniently.
This inspection camera has many applications including HVAC inspection, vent pipe, machine equipment, engine, cable routing, automotive / boat / aircraft inspection.
Features
- Handheld Mini USB Endoscope
- Capture video in AVI format or snapshot image in BMP format
- 30 fps Frame Rate
- 640 x 480 pixels VGA Resolution
- Suitable for hard-to-reach inspection
- f/2.8 lens with 54° viewable angle and 6 cm (2.36 inch) to infinite focal distance
- 4pcs of adjustable white LED for night vision
- 10 mm (0.39 inch) waterproof camera head
- 150 cm (4.9 feets) Flexible Supporting Cable
- Snapshot Button
- USB 2.0 Interface
Specifications
- Flexible cable neck diameter: 4.0 mm (0.16 inch)
- Camera head outer diameter is 10 mm (0.39 inch)
- USB 2.0 interface
- Image Resolution: 640 x 480 pixels
- Lens: f/2.8
- View of angle: 54°
- Focal Distance: 6 cm ~ infinite
- Frame Rate: 30 fps
- Flexible cable Neck: 150 cm long (4.9 feet)
- Item Weight: approx. 60 g (2.11 oz) (excluding accessories)
One Set Included
- 1 x Mini USB Endoscope
- 1 x Software CD
- 1 x Magnet Tip
- 1 x Hook Tip
- 1 x Mirror Tip
- 1 x Sleeve
- 1 x Instruction Manual
- Standard Factory Package
