Specifications
Brushless Motor Blood bank Centrifuge1.DC Brushless mortor
2.small temperature rise,effectively protect samples
3.CE,ISO9001
Brushless Motor Blood bank Centrifuge TD5Z
This desktop low speed centrifuge is a medical centrifuge that manily used for clinical blood (usually with 8*5/7ml rotor or 48*5ml,32*10ml rotor), clinical biochemistry (5ml, 7ml vaccum blood collection tube) and physical examination center of liver function (2x2x96holes microplate)
FEATURES:
1. Equipped with brushless DC motor, bearing from Europe with high quality, running smoothly and maintenance free.
2. Controlled by microcomputer with touching panel and LED display.
3. Stainless steel centrifugal chamber. Small vibration, low noise, durable and easy to clean
4. With overspeed, door interlock, unbalance protection. The rotor can be disinfected at high temperature & high pressure to ensure safety.
5. A proprietary air flow guide design, makes the the centrifuge chamber temperature rise small, can effectively protect the sample.
TECHNICAL PARAMETER
Model |
TD5Z |
Max Speed |
5000r/min |
Max RCF |
4390×g |
Max Capacity |
800ml |
Speed Accuracy |
±50r/min |
Time Range |
0-99min |
Power Supply |
AC 220V 50Hz 10A |
Noise |
≤60dB |
Dimension |
490×400×370(mm) |
Weight |
40kg |
TD5Z ROTOR:
Model |
No. |
Capacity |
Max Speed (r/min) |
Max RCF (xg) |
Tube Dimension (mm) |
|
Swing Rotor |
No.63 |
4×50/100ml |
5000/5500 |
4390/5310 |
Ø38x124 |
No.77 |
32×10/15ml |
4000 |
2810 |
Ø16x85-118 |
|
No.78 |
16×10/15ml |
4000 |
2810 |
Ø16x85-118 |
|
No.81 |
8×50ml |
4000 |
2810 |
Ø38x124 |
|
No.83 |
48/40×5ml |
5000 |
2800 |
Ø14x54 |
|
Microplate rotor |
No.43 |
2×2×96 holes |
4000 |
2300 |
microplate |
An ISO 9001 :2008 certified company
KAIDA Products follows Standards of ISO 13485:2003 AND CE Certified
Remarks:
If you have any question or special requirement about the centrifuge and its accessories, pls don’t hesitate to contact us. Your request will always draw our first attention. Thanks for all your support!
