KL03RH Low Speed temperature controlled centrifuge at 4 degree

Specifications

1.precise temperature control at 4 degree and 37 degree
2.automatic rotor identify
3.10 Accel/Decel mode
4.Over heat protect

KL03RH Low Speed temperature controlled centrifuge at 4 degree



Features:

1. Advanced Control System, Excellent separation

1) Ten kinds of Accel/Decel modes can be selected; User can set up the operate parameter by themselves, to achieve the best centrifugal result.

2) Short running function, easy to diversification centrifugation.

3) Proprietary SCT speed control technical, high efficiency.

4) Proprietary SBT soft brake control technical, to avoid mix up and ensure get maximum specimen.

5) During 4°C and 37°C the temperature accuracy is ±1°C  in static state, temperature control is more precise.

6) Can be stability in the 37°C, and mainly applies to centrifugal sperm and temperature sensitive cell.



2. High Safety, Ease of use

1) Automatic Rotor identification system, no need to select rotor number.

2) Over temperature, over speed, door and unbalanced protection.

3) Steel body, Stainless steel chamber, Steel Protective sleeve.

4) Can take the rotor with aerosol-tight lid for use with hazardous samples.



3. Friendly Display, Humanity Operate

1) LCD, LED multiple-screen display, the Program, Accel/Decel modes, RPM/RCF, Time, Temperature are all easy to set up without any key combination.

2) Microprocessor control, operated data can be saved automatically, can start the instrument with RCF directly, can be store and use 40 kinds of self-defining operating modes directly by user-self.



4. Good parts, Reliable and longlasting

1) Brushless motor which has high torque, "SKF" supper speed bearing, Freon-free compressor from Europe.

2) Aerospace rubber for damping, super duralumin alloy from Aluminum Corporation of China Limited (CHALCO).





TECHNICAL PARAMETER



Model	KL03RH
Max Speed	5000r/min
Max Rcf	3550xg
Max Capacity	800ml
Speed Accuracy	±30r/min
Time Range	1-999min
Temperature Accuracy	±1°C
Temperature Range	-20°C-+40°C
Noise	≤65dB
Power Supply	220V /50HZ 18A
Dimension	630×550×360(mm)
Weight	85kg





Rotor



Model	Capacity	Max Speed	Max RCF	Dimension of tube   (mm)
Swing Rotor	4×50ml/100 ml	5000 r/min	3550×g	Φ38×124
	24×10ml/15ml	4000 r/min	2270×g	Φ16×85-118
	8×50/100ml	4000 r/min	2270×g	Φ28×105-115
	48×5ml	4000 r/min	2230×g	Φ14×54
Microplate Rotor	2×2×96 Holes	4000 r/min	2300×g	Microplate Rotor
Angle Rotor	24×1.5/2.0 ml	5000 r/min	2300×g	Φ10×42



Remarks:

If you have any request of the centrifuge, please feel free to let us know. Your request will always draw our first attention
