25 inch single axis slew drive solar track
Size : 12 inch
Output Torque:18 kN.m
TiltingMomentTorque:271kN.m
Holding Torque:158.3 kN.m
Static Axial Rating:2360 kN
Tracking Precision:≤ 0.15°
Gear Ratio : 150 : 1
Output Torque |
Tilting Moment Torque |
Holding Torque |
Static Axial Rating |
Static Radial Rating |
Dynamic Axial Rating |
Dynamic Radial Rating |
Gear Ratio |
Tracking Precision |
Weight |
18 kN.m |
271 kN.m |
158.3 kN.m |
2360 kN |
945 kN |
590 kN |
470 kN |
150 : 1 |
≤ 0.15° |
204kg |
13300 lbf.ft |
200×10^3 lbf.ft |
117×10^3 lbf.ft |
531×10^3 lbf |
212×10^3 lbf |
133×10^3 lbf |
106×10^3 lbf |
Feature
It is designed in enclosed to resist wind, rainstorm and other harsh environment, it can working outdoor
It can solved the problem of two objects relative rotation.
It is the one of the most widely used slewing drive of H-fang, has been recognized by the Europe and America market
Application
single axis slew drive solar track widely used for relative rotation parts of the construction machines and solar tracking systems.
The solar tracking system Azimuth & Elevation rotation.
Aerial platform Chassis rotation.
Drive the arm rotation of the crane truck
Our Advantage:
1.ISO 9001:2008 certificate,with Hight qualified material, excellent quality
2, Start to produce slewing bearing in 1995, with a professional manufacture team.
3, A 8 years' export experience, excellent good service in any time.
