Product: 48Kw Small Power Diesel Generator With Engine DB58
Genset Technical Data | |
Prime power |
48kW |
Standby power |
54.5kW |
Rated speed |
1500 RPM |
Output frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V |
Noise dB(A) @7m |
100 |
Engine model |
DB58 |
Alternator model |
MP-70-4 |
Diesel Engine Technical Data | |
Engine Model |
DB58 |
Numbers of cylinders |
6 cylinders |
Cylinder arrangement |
Vertical in-line |
Cycle |
4 stroke |
Aspiration |
Naturally |
Bore×Stroke |
102 x 118 mm |
Rated speed |
1500rpm |
Displacement |
5.785 L |
Prime Power/ Speed |
64KW/1500rpm |
Speed Governor |
Mechanical |
Cooling System |
Forced Water Cooling Cycle |
Steady speed droop (%) |
≤5% |
| Total lubrication system capacity (L) | 19 |
| Coolant capacity (engine only)(L) | 12 |
Fuel Consumption at 100% Load |
13.9g/kw.h |
Start method |
24V DC |
Alternator Specification | |
Alternator model |
MP-48-4 |
Alternator manufacturer |
Marathon |
Exciter type |
Single bearing, Brushless, Self-excited |
Rated output prime power |
48 kW |
Rated speed |
1500 RPM |
Rated frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400V(Available with customer requirements) |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation grade |
H |
Protection grade |
IP23 |
Dimension and Weight(for reference only)
Overall size (L*W*H): 2500*830*1208mm
Weight:1100kg
Control System HGM6110
All gensets have a control cubicle (the smart gen HG6110 as standard) mounted on an isolated support, which has the following features.
The control module display for failure information
Overspeed / underspeed
Emergency stop
Low oil pressure
High water temperature
Failure to start
Battery charger failure
Functions Automatic shutdown
Low engine oil pressure
High engine water temperature
Overspeed/underspeed
Failure to start after three attempts
