Auto Pocket Spring Assembling Machine

Name: Auto Pocket Spring Assembling Machine
Brand: SOFTLIFE
SKU: 109753379
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Other, MATTRESS,SOFA

Packaging Type:

Other

Softlife Mattress Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

jiangmen waihai port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Other, MATTRESS,SOFA

Packaging Type Other

Packaging Material Metal

Automatic Grade Automatic

Driven Type Electric

Voltage Customized

Power 4.5KW

Place of Origin Guangdong, China

Brand Name SOFTLIFE

Model Number SL-13A

Dimension(L*W*H) 3500mm*2500mm*1750mm

Weight 950KG

Certification CE.SGS

After-sales Service Provided Engineers available to service machinery overseas

. SL-13A is a new model which is with high efficiency by using a more humanization design and easy operation,

. Using the inverted triangle fixed plate, to make sure each pocket spring in the right position

. The traditional time delay spring positioning has replaced by the orientation of distance, to make it more accurate.

. Achieve straight pattern and honeycomb type mattress;

. With up and down non-woven assembly function;

.Non-woven could be cut automatically after assemble one mattress;

Dimensions	3500mm×2500mm×1750mm
Pocket Height	100-150mm
Spring Diameter	45-65mm
Max. working width	2200mm
Gluing type	Interrupted,continuous ,or bit by bit
Non-woven width	≤2200mm
Non-woven	≥50g/m2
Max non-woven diameter	400mm
Working efficiency	3row/min(45pcs/row)
Air pressure	6KGS/cm3
Power	4.5kw
Weight	950kg
