Help CenterHoist Mechanism System Double Trailer Dump Truck
Related Products
-
Indonesia Style KRM143/167 Auto Chassis Hydraulic Cylinder for Dump TruckUS$ 150 - 300MOQ: 1 Set -
Hydraulic Ram Cylinders Rear DumpUS$ 150 - 300MOQ: 1 Piece
-
2016 First Promotion NEW 5 Stages Hydraulic Cylinder Technical Specifiion From New FactoryUS$ 100 - 150MOQ: 1 Piece
-
Indonesia Style KRM143/167 Auto Chassis Dump Truck Hydraulic HoistUS$ 150 - 300MOQ: 1 Set
-
Hidrolic Hoist Mechanism Complete Set With Hydraulic PartsUS$ 150 - 300MOQ: 1 Piece
Main Data of Hoist mechanism system double trailer dump truck
Hoist Mechanism, Dimensions and Weight (approx.)
Length(mm) |
Width(mm) |
Height(mm) |
Min.Closed Length(mm) |
Weight(kg) |
2945 |
690 |
465 |
1956 |
884 |
Hoist Cylinder and Pump Combination Specification (approx.)
|
Hoist Cylinder KRM220 68" |
Working Pressure (MPa) (Kgf/cm2) |
9.8 |
Gear Pump KP-1505A |
Standard Revolution (rpm) |
800 |
100 | |||||
Inner Diameter (mm) |
220 |
Discharge Volume(ml/rev.) |
148 |
||
Stroke (mm) |
1510 |
Max.Testing Pressure (MPa) (Kgf/cm2) |
|
||
|
Min.Mounting distance (mm) |
1876 |
20.6 |
|||
210 | |||||
|
Piston Rod Diameter (mm) |
100 |
Weight(kg) |
37 |
||
|
Max. pressure (MPa) (Kgf/cm2) |
20.6 |
||||
210 |
Hoist Mounting and Maximum Lifting Capacity
|
Recommended Truck G.W. (kg) |
Body Length(mm) |
Rear Overhang(mm) |
Distance between Load Center to Hinge(mm) |
Distance between trunion to Hinge(mm) |
Rated Lifting Capacity (kg) |
Designed Max. lifting Capacity(kg) (including load weight) |
39000 |
8000 |
1200 |
3000 |
3630 |
20000-29000 |
39000 |
Full set Dump truck krm220LB hydraulic hoist mechanism assy
we can also offer KRM92,KRM140,KRM143,KRM183,KRM201,KRM201A,KRM22048",KRM22062",KRM22068"
Selling Points:
1.High precision , the outer and inner round of telescopic is processed by specific machine
2.Durable and corrosion , the Chrome thickness on the outer surface is up to 0.05mm
3.Stable quality , with imported seal material
4.The upper and lower support shaft is processed by overall forging to make its strength better .
5.In structure ,our front lifting telescopic cylinder is mature and stable as European famous brands
6.In domestic market , most of the front lifting telescopic cylinder with 5390 stroke only have the maximum diameter of 180mm and minimum 100mm , but ours are 185mm and 110mm .So in theory , the lifting strength of our products is upgraded by 7% , and anti-flexural capacity increase 15%.
