Brightway Decanting Centrifuge Features
Brightway is the professional Continuous Decanter Centrifuge Manufacturers and Suppliers.
Brightway decanting centrifuges are designed with practical structure and environmental friendly concept. The middle speed, high speed and variable-speed decanting centrifuges can separate and remove solid phrases in drilling fluids with safe, consistent, and efficient working performance, satisfying different request for solids control in oil drilling, drilling waste management, and other industrial applications.
1. Main body & core components adopt Q345 high-strength wear-resistant alloy material.
2. Screw propeller material: 1CR18NI9TI
3. Bowl: SS316 material
4. Bearing: SKF or FAG.
5. Explosion-proof electric control box: The electric components are well-known brand as SIEMENS, SCHNEIDER or ABB.
6. Discharge port protected by tungsten carbon alloy ring or coating.
7. Parts in contact with material are stainless steel.
Brightway Decanting Centrifuge Parameters
| Model | BWLW450X842N | BWLW450X1250N | BWLW355X1250N | BWLW365G/VFD |
| Bowl Diameter | 450mm | 450mm | 355mm | 365mm |
| Bowl Length | 842mm | 1000mm | 1250mm | 1250mm |
| Bowl Speed | 1800 rpm | 2200 rpm | 3200 rpm | 0-3500 rpm |
| G-Force | 815 | 1220 | 2035 | 2500 |
| Separation Point | 5-7μm | 5-7μm | 2-5μm | 2-5μm |
| Main Drive | 22Kw-4p | 30Kw-4p | 30Kw-4p | 37Kw-4p |
| Back Drive | 5.5Kw-4p | 7.5Kw-4p | 7.5Kw-4p | 7.5Kw-4p |
| Max Capacity | ≤40m³/h | ≤60m³/h | ≤40m³/h | ≤40m³/h |
| Weight | 2950kg | 3150kg | 2850kg | 2950kg |
| Dimension | 2380x1560x1350mm | 2540x1560x1350mm | 2810x1490x1350mm | 3412x1600x1875 mm |
Brightway Decanting BWLWF series Centrifuge
BWLW365G/VFD Decanting Centrifuges
BWLW450X1250N Decanting Centrifuges
