XLPE Armored Power Cable

Name: XLPE Armored Power Cable
Brand: San Heng
SKU: 109631085
Availability: InStock

US$ 0.1 - 100 MOQ: 500 Meters

Key Specifications

Place of Origin:

Henan, China

Brand Name:

San Heng

Model Number:

YJLV22

Henan Sanheng Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao port or as your request

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name San Heng

Model Number YJLV22

Insulation Material XLPE

Type Low Voltage

Application Overhead

Conductor Material Other, Copper or alminum

Jacket PVC

Specifications

-CCC ISO IEC
-Prompt delivery, quality assured
-Manufacture more than 20 years
-Made by high purity aluminum

Detailed Description of PVC shealth amored power

1. the armored power cable is made complying with the national standard and have pass the CCC

(China Compulsory Certification) which contains the recognization of national security certificate (CCEE),

imports of safety and quality licensing system (CCIB), China Certification Electromagnetic Compatibility (EMC).

2. the temperature of the conductor in the working time is no more than 70°C

3. The specification: YJV22

4. The rated voltage is 0.6/1 kv

5. The core count* the sectional area of the conductor(mm2)

(We can also product the electrical wire and cable as your request! You can decide the core count and cross

section of the conductor, as well as the jacket and insulation.)

Technical Data of PVC shealth amored power (Cu/XLPE/PVC)

Number of cores Nominal cross section(mm²)	Insulation (mm)	Sheath (mm)	Nominal Overall diameter (mm)	Nominal cable weight (kg/km)	Max conductor resistance at 20°C (Ω/km)	Max current capacity in Air (A)
1 x 1.5	XLPE 0.7	PVC 1.4	5.6	46	12.1	26
1 x 2.5	XLPE 0.7	PVC 1.4	6.0	58	7.41	34
1 x 4	XLPE 0.7	PVC 1.4	6.5	76	4.61	44
1 x 6	XLPE 0.7	PVC 1.4	7.0	98	3.08	56
1 x 10	XLPE 0.7	PVC 1.4	7.8	141	1.83	77
1 x 16	XLPE 0.7	PVC 1.4	8.7	202	1.15	100
1 x 25	XLPE 0.9	PVC 1.4	10.2	299	0.727	130
1 x 35	XLPE 0.9	PVC 1.4	11.2	398	0.524	160
1 x 50	XLPE 1.0	PVC 1.4	12.8	548	0.387	195
1 x 70	XLPE 1.1	PVC 1.4	14.4	745	0.268	245
1 x 95	XLPE1.1	PVC1.5	16.1	988	0.193	300
1 x 120	XLPE1.2	PVC1.5	17.8	1236	0.153	349
1 x 150	XLPE1.4	PVC1.6	19.8	1537	0.124	400
1 x 185	XLPE1.6	PVC1.7	21.8	1888	0.099	465
1 x 240	XLPE1.7	PVC1.8	24.4	2423	0.0754	550
1 x 300	XLPE1.8	PVC1.9	26.7	3003	0.0601	635
1 x 400	XLPE2.0	PVC2.0	30.5	3974	0.0470	745
1 x 500	XLPE2.2	PVC2.2	33.7	4943	0.0366	860
1 x 630	XLPE2.4	PVC2.2	37.4	6197	0.0283	990
