Help CenterHigh Quality PVC Sheath XLPE Insulated 5x16mm2 Power Cable
Related Products
-
High Quality XLPE Insulated 4x16mm2 Power CableNegotiableMOQ: 5 Kilometers -
XLPE Insulated 3x2.5mm2 Power CableNegotiableMOQ: 5 Kilometers
-
H03VV-F/R2V 3g Core Flexible Cable 2.5mm2US$ 0.1 - 4.22MOQ: 1 Kilometer
-
R2V 2 Core 1.5mm2 Flexible Electric WireUS$ 0.1 - 4.22MOQ: 1 Kilometer
-
Single Strand Pvc Insulated Single Core Soft Single Strand CableUS$ 0.5 - 80MOQ: 5 Kilometers
Specifications
1. Cable production with 30 years' experience2. Prompt delivery, quality assured - CCC .
3. High quality & prompt delivery
PVC insulated power cable
1.Using Feature:
(1.) The long-time working temperature of cable should not be highter than 70 °c
(2.) When core is in short-circuit(max 5s) the temperature should not exceed 160 °c.
(3) While installation the ambient temperature should not be lower than 0 °c, bending radius of the cable;
For single no-armored cable, it is not less than 20 times of outer diameter
For single-core armored cable, it is not less than 15 times of outer diameter
For multi-core no-armored cable, it is not less than 15 times of outer diameter
For multi-core armored cable, it is not less than 12 times of outer diameter.
2. Specification Size and Technical Data:
Core number |
Nominal Section(mm²) |
D.C.Resistance in 20 °C(Ω/km) |
O.D.(mm) |
Reference Weight(Kg/km) |
||
CU |
AL |
Cu |
Al |
|||
|
3 core |
1.5 |
17 |
— |
10.7 |
141 |
— |
2.5 |
23 |
17 |
11.5 |
180 |
134 |
|
4 |
30 |
23 |
13.6 |
255 |
183 |
|
6 |
39 |
30 |
14.9 |
341 |
228 |
|
10 |
54 |
41 |
16.3 |
470 |
285 |
|
16 |
71 |
55 |
19.6 |
697 |
363 |
|
25 |
99 |
76 |
23.4 |
1049 |
568 |
|
35 |
120 |
92 |
25.8 |
1370 |
702 |
|
70 |
186 |
143 |
28.7 |
2350 |
1031 |
|
95 |
227 |
175 |
32.8 |
3144 |
1355 |
|
120 |
262 |
203 |
34.9 |
3882 |
1624 |
|
185 |
352 |
272 |
43.9 |
5945 |
2464 |
|
240 |
420 |
324 |
49.2 |
7647 |
3132 |
|
|
3+1 core |
3×4+1×2.5 |
31 |
23 |
14.2 |
289 |
202 |
3×6+1×4 |
40 |
31 |
15.8 |
386 |
262 |
|
3×10+1×6 |
54 |
42 |
17.3 |
548 |
329 |
|
3×16+1×10 |
72 |
56 |
20.5 |
793 |
408 |
|
3×25+1×16 |
98 |
75 |
24.6 |
1196 |
608 |
|
3×35+1×16 |
122 |
94 |
26.9 |
1518 |
744 |
|
3×50+1×25 |
153 |
118 |
27.9 |
2032 |
931 |
|
3×95+1×50 |
231 |
178 |
35.1 |
3683 |
1583 |
|
3×120+1×70 |
267 |
207 |
37.9 |
4617 |
1924 |
|
3×150+1×70 |
315 |
242 |
41.7 |
5563 |
2306 |
|
3×185+1×95 |
362 |
279 |
46.4 |
6929 |
2854 |
|
International standard packing: pp bag, woven bag, wooden drum, steel drum, or as per esteemed customers' request.
Quality First ! Customer First ! Service First !
Our products have been repeatedly tested by National Ministry of Electrical Material Test Center, National Electric Wire and Cable Supervision & Inspection Center and Wire and Cable Products Supervision & Inspection Center of Henan province to beQualified Products. We have got China electical products safety certification and in accordance with the IEC standard.
If you have any problem , please don't hesitate to contact us.Your inquiry is welcomed at anytime.
we are confident to render our best service to you with promptness & efficiency.
