Specifications
CCA wire--copper clad aluminum-Wire property: between those of aluminum and copper.
-Prompt delivery, quality assured.
1. CCA wire --Copper-clad aluminum wire, commonly abbreviated as CCAW or CCA, is a conductor composed of an inner aluminum core and outer copper cladding.
2. CCA wire (copper clad aluminum wire) is a bimetallic wire with a copper cladding concentrically covering an aluminum core, and it combines the characteristrics both of the excellent conductivity of copper and the light-weight of aluminum, so it is a ideal material for most electrial conductor applications, such as coaxial cables , high-frequency signal transmission cables, control cables, electromagnetic cables and many other fields.
3. Advantages:
Copper clad aluminum wire is produced by international advanced welding technology. The copper adopts the pure copper with 99.97% above density, copper layer is of high density, and good conductivity. Copper layer and aluminum wire can reduce the raw-materials largely the buyer.
4..Application:
a. For the high-frequency singal transmission: Flexible RF coaxial cable; Leaky in inner cable conductor ; Network cable inner conductor; Micro coaxial inner conductor; coaxial cable conductor material within the frist 50Ω; RF cable. Flexible RF coaxial inner conductor.
b. For electricity transmission: Wire material; Fuse; Power cable conductor; Bush conductor wiring construction materials;
c. For Bus conductor materials, ect.: Cars, Iocomotives cable conductor; Computer cables, control cables and other data cables with conducyors
d. For others: Audio, Video conductor, power line conductors, Computer peripheral lines, Computer lines row conductor material.
Application areas:
(1)Braided shielding wires of power cables
(2)Overhead lins for power transmission and telephone lines
(3)Carrier cables and trolley lines of electric railway and rail transit lines
(4)Conductor material inside the coaxial cables of CATV subscriber lines and service entrance lines
(5)Conductor material inside LAN cab les,access network cables and outdoor cbales
5. Parameters:
1) Strandard carried out: SJ/T 11223-2000, ASTM B 566-93
2) Copper by volume (%): 10%+2%; 15%+2%
3) Copper by weight (%): 26.8%+2%; 36.8%+2%
4) Tensile strength: annealed , hard
