Car Painting Room/ Automotive Spray Booth
Dimensions: |
Length (mm) |
Width (mm) |
Height (mm) |
Booth Outside |
7,050 |
5,250 |
3,600 |
Booth Inside |
6,900 |
3,900 |
2,750 |
Entrance Door |
Equipped with Handle & Lock |
3,000 |
2,700 |
Personnel Door |
Equipped with Handle & Anti-Explosion Lock |
800 |
2,000 |
Features: |
Total Power 14.5 KW; 380v/3phase/50hz |
Noise < 80 db |
1. Walls & Ceiling |
- Panels 75 mm thick, with foam in the middle and color steel on both sides |
|
2. Basement System |
- Metal Pedestal (Galvanized), with Filter Tray* 2rows & Ramps a couple - Grid Plates (Galvanized)* 2rows - Diamond Plates (Powder Coated or Galvanized)* 3rows |
|
3. Heating System |
- Diesel Burner (Italy RIELLO, G20)* 1unit - Heating Exchanger (Stainless Steel material)* 1unit - 5~10 minutes reaching the baking temperature 60~80 degree Celsius - Cabinet (rock-wool insulation) * 1unit; Air Ducts * 2pcs |
|
4. Filter System |
- Primary Filter* 1set, filtering rate > 83% - Air-Intake Filter* 1set, filtering rate > 97% - Air-Exhaust Filter* 1set, filtering rate > 70% |
|
5. Air System |
- Air-Intake Fans* 2units, Centrifugal Fans with 4 KW motor each - Air-Exhaust Fan* 1unit, Centrifugal Fans with 4 KW motor - Air velocity 0.30 m/s - Cabinet for the fans* 1unit, and Air Ducts* 3pcs, and Air Damper (pneumatic)* 1unit |
|
6. Illumination |
- Ceiling Lights * 32pcs, 36w each, with Light Fixtures, anti-explosion design - Side Lights * 32pcs, 36w each, with Light Fixtures, anti-explosion design |
|
7. Control Panel |
- *1unit, including Spray Switch, Baking Switch, Light Switch, Emergency Stop, etc. |
|
** Included |
- All Hardware, Fasteners, and Sealants |
|
