Help Center2W 2.4G Small Size Wifi Signal Amplifier RF610
Related Products
-
Long Distance 2 Watt 2.4Ghz Wifi Signal Booster Indoor Signal AmplifierNegotiableMOQ: 5 Pieces -
2400-2500MHz 33dbm Output Power Wifi Mini Cell Phone Signal Booster KW30D-WIFINegotiableMOQ: 2 Pieces
-
2.4G Wlan Network Mini Wifi Signal Booster KW30D-WIFINegotiableMOQ: 2 Pieces
-
High Power 4W Wifi Booster Signal Repeater RF600NegotiableMOQ: 5 Pieces
-
2.4G 4W Outdoor Wifi Network Repeater RF600NegotiableMOQ: 2 Pieces
Specifications
wifi signal amplifier1:IEEE 802.11b/g/n compatible
2:high power:2Watt
3:Certificate:CE
4:larger coverage
2W 2.4G small size wifi signal amplifier
| Operating frequency | 2400-2483.5MHz |
| Operating mode | TDD |
| Signal standard | IEEE 802.11b/g/n |
| Minimum input power | 3dBm |
| Maximum input power | 20dBm |
| Maximum output power | 33dBm (2w) |
| Uplink gain | 16dB |
| Downlink gain | 12dB |
| Noise figure | ≤ 2.5dB |
| Delay | <1uS |
| Operating temperature | -20°C to + 55°C |
| Weight | 129g |
| AP/Router Interface | SMA Female |
| Antenna Interface | RP-SMA Male |
Instructions :
1:Connect Antenna to the Wi-Fi Booster.
Caution: The Booster antenna interface can only connect antenna, Don’t connect to any other wireless products in any case, otherwise it will result in equipment malfunction or damage.
2:Connect Wireless AP/Router or Wireless Network Card to the Wi-Fi Booster.
Tips: Users can also use other shielded cables to connect, but the cable length should be as short as possible, preferably not exceeding 3m.
3:Power up the Wi-Fi Booster.
At first, the color of the LED is green. When the data is being transmitted, the light will turn red. The more dense data transmission, the faster color change of the LED.
4:Adjust the Antenna position and angle,make the Wi-Fi Booster receive the best signal .
Tips: You can use third-party software such as Network Stumbler or WirelessMon to detect the signal of Wireless AP/Router / Wireless Network Card, and adjust the antenna angle to achieve the strongest signal.
Attentions :
1: Keep at least 1m distance between Wi-Fi Booster antenna and any other 2.4G wireless products, Otherwise may result in equipment malfunction or damage.
2: This type of Wi-Fi Booster is not waterproof, please do not put it in the humid environment.
3: Do not use it where the place surrounded by a large number of metals.which will make the electromagnetic signal blocked.
4: If the user install antenna in the high location, you need to take protection measures for lightning.
5: After the Wi-Fi Booster is turned on, can not remove the Antenna, otherwise may damage the Wi-Fi Booster.
