GSM 900/1800/2100Mhz 2g/3g/4g Signal Booster/repeater

Name: GSM 900/1800/2100Mhz 2g/3g/4g Signal Booster/repeater
Brand: Lintratek
SKU: 109535971
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Lintratek

Model Number:

KW23F-GDW

Foshan Lintratek Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

GUANGDONG

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Lintratek

Model Number KW23F-GDW

Product Description

GSM 900/1800/2100Mhz 2g/3g/4g signal booster/repeater

Specification

Model No		KW23F-DW
Parameter data		Uplink	Downlink
Frequency Range		uL:890-915MHZ UL:1710-1785mhz UL:1920-1980mhz	DL:935-960mhz DL:1805-1880mhz DL:2110-2170mhz
Output Power		33 ±2dBm	33 ±2dBm
Gain		85 dB	85 dB
Bandwidth		Wide Band
Automatic Gain Control		>20dB
Ripple in Band		≤5dB
Intermodulation Products	9KHz~1GHz	≤ -36 dBm
	1GHz~12.75GHz	≤ -30 dBm
Spurious Emission	9KHz~1GHz	≤ -36 dBm
	1GHz~12.75GHz	≤ -30 dBm
Noise Figure @ max. gain		≤ 6 dB
VSWR		≤3
MTBF		>50000 hours
Power Supply		AC:90~265V, 50/ 60Hz;DC:12V 3A
Power Consumption		< 20W
Impedance		50 ohm
Mechanical Specification
RF Connector		N-Female
Cooling		Heatsink Convection cooling
Dimensions (D x W xH )		25015020 mm
Weight		3Kg
Installation Type		Wall Installation
Environment Conditions		IP40
Humidity		< 90%
Operating Temperature		-10°C ~ 55°C
