Help Center2G 3G 4G Signal Amplifier With LCD Screen/Lintratek Mobile Signal Booster
Related Products
-
Gsm Repeater With LCD Screen Display 1800mhz Booster/amplifier Mobile Signal ReceiverUS$ 1 - 45MOQ: 5 Pieces -
Good Reputation Gsm1800mhz Telecom Mobile Signal BoosterUS$ 1 - 35MOQ: 3 Pieces
-
High Gain 1800mhz Professional Amplifier Dcs Signal Repeater With Yagi AntennaUS$ 1 - 95MOQ: 1 Piece
-
Low Gain 1800mhz Dcs Telecom Mobile Signal Booster for Little House UseUS$ 1 - 80MOQ: 3 Pieces
-
GSM 1800 Signal Booster Repeater Amplifier Lintratek With LCD Display FunctionUS$ 1 - 47MOQ: 1 Piece
Cell phone becomes especially helpful when people get into critical situations. In case of emergency a timely call can save somebody's life.
Unfortunately, there are still some places where they can find themselves "out of coverage" ,no signal at all... Usually those places are either too far from the cell phone base station or located inside underground constructions, for example:
- Parking lots, tunnels
- Big stores, office buildings
- Cars, boats etc.
- House in remote areas
2G 3G 4G signal amplifier With LCD screen/Lintratek mobile signal booster
A regular cell phone repeater consists of: (full kit)
- 1 -Outdoor antenna log periodic antenna(or wall mounted, yagi antenna)
- 2 - Indoor Omni ceiling antenna( panel antenna)
- 3 – Power adapter
- 5 - User manual
- 6 - Cell phone repeater
- 7- 10 meters outdoor cable and 1 meter indoor cable
Specification
Model No |
|
||
Parameter data |
Uplink |
Downlink |
|
Frequency Range |
DCS |
1710-1785mhz |
1805-1880mhz |
Output Power |
20±2dBm |
20±2dBm |
|
Gain |
70 ±2 dB |
70±2dB |
|
Bandwidth |
75M |
||
Ripple in Band |
≤5dB |
||
Spurious Emission |
9KHz~1GHz |
≤ -36 dBm |
|
1GHz~12.75GHz |
≤ -30 dBm |
||
VSWR |
≤3 |
||
MTBF |
>50000 hours |
||
Power Supply |
AC:100~240V, 50/ 60Hz;DC:5V 1A |
||
Power Consumption |
< 5W |
||
Impedance |
50 ohm |
||
Mechanical Specification | |||
RF Connector |
N-Female N |
||
Dimensions (D*W*H ) |
140*95*30(mm) |
||
Net weight |
< 0.7Kg |
||
Packing size (D*W*H ) |
250*240*65(mm) |
||
Gross weight |
< 1Kg |
||
Installation Type |
Wall Installation |
||
Environment Conditions |
IP40 |
||
Humidity |
< 90% |
||
Operating Temperature |
-10°C ~ 55°C |
||
