Help CenterFR-LSOH Insulating Compound
US$ 1,000 - 3,000
MOQ: 3 Tons
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
MG
Model Number:
MG80012(H)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
FR-LSOH Filling CompoundUS$ 1,000 - 3,000MOQ: 3 Tons -
Halogen Free Flame-retardant Polyolefin Compound for Insulation and Jacket of Cable/wireUS$ 1,000 - 3,000MOQ: 3 Tons
-
Flame-retardant Low Smoke Non-halogen Polyolefin Filling (bedding) Compound for Wire/cableUS$ 800 - 2,000MOQ: 3 Tons
-
Flexible LS0H Elastic Compound for Wire/cableUS$ 800 - 2,000MOQ: 3 Tons
-
Flame-retardant Halogen Free Fire-retardant Polyolefin Compound for InjectionUS$ 800 - 2,000MOQ: 3 Tons
Place of Origin
Jiangsu, China
Brand Name
MG
Model Number
MG80012(H)
Specifications
Introduction:Flame-retardant polyolefin low-Smoke non-halogen compound can be uesd for power cable,telecommunication&eletrical
♦ Variety Colours
♦ Workshop show
♦ Company Certifications:
◊ ISO 9001:2008
◊ ISO 14001:2004
◊ Certification of UL
| Test Items | Unit | Typical Value | ||
| MG80012(J) | MG80012(H) | MG80011(G) | ||
| Density | g/cm³ | 1.47 | 1.46 | 1.60 |
| Tensile strength | Mpa | 12.3 | 11.7 | 10.2 |
| Elongation at break | % | 190 | 180 | 100 |
| Air oven again | °C×h | 100×168 | 100×168 | - |
| Tensile strength after again | 13.5 | 12.8 | - | |
| Variability of Tensile strength | % | +10 | +9.4 | - |
| Elongation at break after again | 168 | 155 | - | |
| Variability of Elongation at break | % | -11.5 | -13.9 | - |
| low temperature impact Brittleness | °C | -25 pass | -25 pass | - |
| 20°C Volume resistivity | Ω.cm | 5.1×1014 | 1.5×1013 | - |
| Dielectric strength | MV/m | 28 | 27 | - |
| Oxygen index | % | 34 | 35 | 45 |
| HCI Acid gas emission | mg/g | 0 | 0 | 0 |
| PH | 6.0 | 6.3 | 5.4 | |
| Conductivity | μ s/mm | 0.4 | 0.6 | 1.0 |
| (1.0mm)Smoke density | flame | 48 | 55 | 64 |
| non-flame | 142 | 151 | 168 | |
