Specifications
1. Eco-friendly2. Perfect electric performance
3. Good flame-retardant
4. Good flexibility
5. Toxic gas emission free
MG80015 (86±2A) Flame-retardant polyolefin low-Smoke non-halogen elastomer compound
MG80015-3 (80±2A) Flame-retardant polyolefin low-Smoke non-halogen elastomer compound
MG80015-5 (70±2A) Flame-retardant polyolefin low-Smoke non-halogen elastomer compound
Flame-retardant polyolefin low-Smoke non-halogen thermoplastic elastomer compound is based on polyolefin, which is mixed with abio-flame -retardant and antioxidant etc. It features soft texture and low smoke density, which is the excellent substitute for soft PVC in soft cable and home electric wires etc.
Test Items |
Unit |
Typical Value |
||
MG80015 |
MG80015-3 |
MG80015-5 |
||
Density (23°C) |
g/cm3 |
1.36 |
||
Hardness (Shore A) |
A |
86 |
||
Tensile strength |
MPa |
11.3 |
||
Elongation at break |
% |
290 |
||
Oven aging condition |
°C x h |
100 x 168 |
||
Tensile strength after aging |
12.4 |
12.4 |
13.1 |
|
Variable rate of Tensile strength |
% |
+9.7 |
+14.8 |
+10 |
Elongation at break after aging |
260 |
290 |
265 |
|
Variable rate of Elongation at break |
% |
-10.3 |
-17.1 |
-14.5 |
Low temperature brittleness |
°C |
-25 pass |
-25 pass |
-25 pass |
20°C Volume resistivity |
Ω·cm |
6.2x101 |
5.9x1014 |
8.6x1014 |
Dielectric strength |
MV/m |
27 |
27 |
28 |
Oxygen index |
% |
34 |
31 |
30 |
HC1 Acid gas emission |
mg/g |
0 |
0 |
0 |
pH |
6.1 |
6.0 |
6.3 |
|
Conductivity |
μs/mm |
0.4 |
0.5 |
0.3 |
Dm(1.0mm) Smoke density |
flame |
57 |
55 |
42 |
non-flame |
162 |
151 |
147 |
|
♦ Variety Colours
♦ Workshop show
♦ Company Certifications:
◊ ISO 9001:2008
◊ ISO 14001:2004
◊ Certification of UL
