Help CenterHalogen Free Flame-retardant Polyolefin Compound for Insulation and Jacket of Cable/wire
Related Products
-
Flame-retardant Low Smoke Non-halogen Polyolefin Filling (bedding) Compound for Wire/cableUS$ 800 - 2,000MOQ: 3 Tons -
Flexible LS0H Elastic Compound for Wire/cableUS$ 800 - 2,000MOQ: 3 Tons
-
Flame-retardant Halogen Free Fire-retardant Polyolefin Compound for InjectionUS$ 800 - 2,000MOQ: 3 Tons
-
Flame-retardant Low Smoke Non-halogen Injection Purpose Polyolefin CompoundUS$ 800 - 2,000MOQ: 3 Tons
-
FR Low Smoke Low Halogen Radiation Cross-linked Flexibie EVA Compound for Wire & CableUS$ 800 - 2,000MOQ: 3 Tons
Specifications
1. Enviromental friendly2. Good flame-retardant
3. Easily processed
4. Permanent performance
5. Excellent flexibility
♦ About Suzhou Mega Plastics
Suzhou Mega was established in 2001, and betgan to develop environmentally conscious polymer compounds. Now, we are known as the lead manufacturer and supplier of PVC and LSHF compounds to producers around the world. Our customers come mainly from China, Taiwan, North America and Africa. Quality products with a commitment ot excellent customer service, Suzhou Mega manufactures more than 20,000 tons of compounds that comply with various global safety standards, such as the Rosh, UL and REACH, which are shipped to domestic and oversea markets alike.
♦ Product Application
Apart from being used widely in the cable and wire industry, Mega's polymer compounds have a variety of applications, such as in the automotive, tool handle, toys, medical tubing and other industrial and residential applications.
For each application, our engineers at Mega will customize and design particular formulation and process to meet each requirement of the compound, including hardness, color and cost. They will cooperate closely with customers to make sure that each specification of the compound is met.
♦ This Model
Introduction:
Irradiation cross-linkable flame-retardant polyolefin low-Smoke non-halogen compound is based on polyolefin resin, which is mixed with non-halogen flame retardant, cross-linkable agent, and other process agent, to knead, plastify, and then extrude into pellets. It has excellent mechanical property, oil resistance, electirc property, flame-retardant property and processing properties. Moreover, it features the advantage of no halogen and low smoke amount giving out, which can be used in power cable, control cable, marine cable, optical cable and signal cable etc.
MG80017-90(J/H) 90°C irradiation cross-likable Flame-retardant polyolefin low-Smoke non-halogen insulating(sheating) compound
MG80017-105(J/H) 105°Cirradiation cross-linkable Flame-retardant polyolefin low-Smoke non-halogen insulating(sheating) compound
MG80017-125(J/H) 125°C irradiation cross-linkable Flame-retardant polyolefin low-Smoke non-halogen insulating(sheating) compound
| Test Items | Unit | Typical Value | ||
| MG80017-90(J/H) | MG80017-105(J/H) | MG80017-125(J/H) | ||
| Density(23°C) | g/cm3 | 1.45 | 1.44 | 1.45 |
| Tensile strength | MPa | 12.3 | 12.7 | 13.1 |
| Elongation at break | % | 220 | 210 | 200 |
| Hot setting test | 200°C x 15min,0.2MPa | |||
| Elongation under lood | % | 65 | 70 | 80 |
| Permanent elongation after cooling | °Cxh | 121x168 | 136x168 | 158x168 |
| Retaintion of Tensile strength | % | 109 | 112 | 110 |
| Retaintion of Elongation at break | % | 89 | 87 | 85 |
| low temperature impact Brittleness | °C | -25 pass | -25 pass | -25 pass |
| 20°C Volume resistivity | Ω.cm | 5.6x1014 | 3.7x1014 | 4.5x1014 |
| Dielectirc strength | MV/m | 26 | 28 | 27 |
| Oxygen index | % | 34 | 35 | 33 |
| Acid gas emission | mg/g | 0 | 0 | 0 |
| pH | 5.9 | 6.0 | 5.8 | |
| Conductivity | μs/mm | 0.8 | 0.7 | 0.5 |
| Dm(1.0mm) Smoke density | flame | 56 | 61 | 54 |
| non-flame | 152 | 159 | 162 | |
Irradiation dosage:
Irradiation dosage is different from the cable and da, genlerally 10-15MRAD recommended.
♦ Variety Colours
♦ Industry Listings and Certifications
Product Safety: UL, CSA, VDE & CCC
Quality Management System:ISO9001-2004
Environment Managemetn: ISO14001-2004
♦ Well-Furnished Office Space
♦ Advanced Laboratory
With highly-skilled staff and well-equipped laboratory, Suzhou Mega triple tests each of the compound that it produces to ensure the products consistently meet ech customer's requirements. We are now able to perform the following testing procedures: 1) tensile strength, 2) elongation, 3) gravity, 4) air oven aging, 5) color meter, 6) water resistance, 7) oil resistance. Additionally, Mega also uses atomic abosroption spectrometry (Aa) and X-Ray spectrometry to analyze environmental sensitive elements of raw materials, so as to ensure that the products comploy withRoSH standards.
♦ Clean & Organized Warehouse
♦ International Certification & Recognition
Product Safety: UL, CSA, VDE & CCC
Quality Management System:ISO9001-2004
Environment Managemetn: ISO14001-2004
◊ ISO 9001:2008
◊ ISO 14001:2004
◊ Certification of UL
♦ Green & Environmental
Mega is extremely conscious of the environment, and is therefore committed to provide customers with accurate information about our products and production processes. We ensure that these processes align with and exceed industry standards. We are proud to work cooperatively iwth each of our customers to address their product and market needs. We are committed to continue to find new ways to formulate new and existing products that will have minimal hazardous ingredients and effects on the environment. Our green compliance system will continue to be Mega's core competitive advantage as the market shifts and desire better and higher quality products, while causing minimal harm to the environment.
♦ Contact Information
If you would like to have more information about our products or are interested in establishing business relationship with us, feel free to reach us at:
Tel: 86-512-65275752
Fax: 86-512-65277403
Phone: 86-13404235070
Website:
If possible, please include the following information in your inquiry.
- Density
- Color
- Shore Hardness
- Mechanical Properties
- Electrical Properties
- Flame-retardant Grade
- Others
We look forward to hearing back from you! :)
