Mobile Phone Signal Booster for 3G 2100mhz UMTS WCDMA 3g Indoor Signal Booster Cell Phone Signal Amplifier
US$ 1 - 215
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
LINTRATEK
Model Number:
KW30F-WCDMA
Payment & Shipping
Payment Methods:
Port of Shipment:
GUANGDONG
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1Watt Mobile Signal Booster for 3G 2100MHz,cell Phone Signal Amplifier Cover 2500sqm, Gsm Signal Booster 3gUS$ 1 - 215MOQ: 1 Piece -
80dB Gain 1 Watt 3G Signal Repeater,UMTS 2100mhz WCDMA Mobile Phone Signal Booster,cover 3000sqm 3g Indoor Signal BoosterUS$ 1 - 215MOQ: 1 Piece
-
KW30F-WCDMA,1 Watt 3G Signal Repeater,2100mhz WCDMA UMTS Mobile Signal Booster,cover 2000sqm Cell Phone Signal AmplifierUS$ 1 - 215MOQ: 1 Piece
-
3g Indoor Signal Booster/3g Signal Amplifier/2100mhz UMTS WCDMA Mobile Signal Booster Mini SizeUS$ 1 - 45MOQ: 1 Piece
-
KW17A-WCDMA Mobile Signal Booster From Lintratek 3g Cell Phone Signal Amplifier /mini Size Signal Repeater 2100mhzUS$ 1 - 45MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
LINTRATEK
Model Number
KW30F-WCDMA
Product Description
mobile phone signal booster for 3G 2100mhz UMTS WCDMA 3g indoor signal booster cell phone signal amplifier
Specification Details
| Model No | KW30F-WCDMA | ||
| Parameter data | Uplink | Downlink | |
| Frequency Range | CDMA&GSM850 | 824~849 MHz | 869 ~ 894 MHz |
| GSM | 890~915 MHz | 935 ~ 960 MHz | |
| DCS | 1710~1785 MHz | 1805 ~ 1880 MHz | |
| PCS | 1850~1910 MHz | 1930 ~ 1990 MHz | |
| AWS | 1710~1755 MHz | 2110 ~ 2155 MHz | |
| WCDMA | 1920~1980 MHz | 2110 ~ 2170 MHz | |
| Output Power | 27 ±2dBm | 30 ±2dBm | |
| Gain | 75 ±2 dB | 80±2dB | |
| Bandwidth | 25M/25M/75M/60M/45/60M | ||
| Ripple in Band | GSM≤6dB,DCS≤6dB,WCDMA≤5dB,PCS≤6dB | ||
| Spurious Emission | 9KHz~1GHz | ≤ -36 dBm | |
| 1GHz~12.75GHz | ≤ -30 dBm | ||
| VSWR | ≤3 | ||
| MTBF | >50000 hours | ||
| Power Supply | AC:100~240V, 50/ 60Hz;DC:5V 1A | ||
| Power Comsumption | < 5W | ||
| Impedance | 50 ohm | ||
| Mechanical Specification | |||
| RF Connector | N-Female | ||
| Dimensions (D*W*H ) | 270*170*60(mm) | ||
| Packing size (D*W*H ) | 370*290*85(mm) | ||
| Gross weight | < 4Kg | ||
| Installation Type | Wall Installation | ||
| Environment Conditions | IP40 | ||
| Humidity | < 90% | ||
| Operating Temperature | -10°C ~ 55°C | ||
Step 1: Install the outdoor antenna in a suitable place
Step 2: Connect the outdoor antenna to the booster “outdoor” side by cable and connector
Step 3: Connect the indoor antenna to the booster “indoor” side by cable and connector
Step 4: Connect to the power
Note: Connect outdoor (BTS) port with outdoor antenna, connect indoor ANT(MS) port with indoor antenna, outdoor antenna is mounted at a higher position. Both antennas should be 10 meters far away from each other and must be separated by wall.
100% Real Shooting
