0.25mm EDM brass wire (Manufacturer)
Copper Wire
Cu(Min): 63.5%-65%
Weight: 1kg,5kg,20kg,100kg,250kg.
Packing: 1kg,5kg,20kg,/spool,100kg,250kg/drum,or as your demand.
wooden case,iron case,vellum paper
Wire diameter: 0.1-0.3mm
Tensile Strength: 1000 N/mm2, 900 N/mm2, 500 N/mm2, 450 N/mm2,
Material: T1,T2,TU1,TU2,H96,H85,H70,H68,H65,H63,H62,H59,C1020,C1100
- Features:
1.Good wear resistance;
2.Excellent corrosion resistance;
3.High intensity;
4.Hot Forging performance;
5.Good cutting performance;
6.Self-lubricating performance.
7.High conductivity.
- Specifications:
Condition |
Diameter (mm) |
Tolerance (mm) |
Tensile Strength (N/mm2) |
Type of Spool (Standard Weight) |
|
Hard |
0.10 |
±0.001 |
≥980 |
DIN125(3kg,3.5kg) |
0.15 |
±0.001 |
≥980 |
||
0.20 |
±0.001 |
≥980 |
DIN125(3kg,3.5kg) P5(5kg) DIN160(7kg,8kg) DIN200(15kg,16kg) |
|
0.25 |
±0.001 |
≥980 |
||
0.30 |
±0.001 |
≥980 |
||
Semi-hard |
0.25 |
±0.001 |
480—520 |
|
0.30 |
±0.001 |
|||
Soft |
0.25 |
±0.001 |
380—420
|
|
0.30 |
±0.001 |
1.We will maintain effective and efficient communications with our customers.
2.We provide first-class quality control and after-sale services.
3.With warm heart patience and vigor as the foundation of the enterprise , we provide most
customers with quality after-services, so as to protect all customer interest.
Products are involved in
1. W/EDM spare parts: wire guide/diamond guide, water nozzle, power feed contact, isolator plate, rollers, belt, cable wire, guide base.
2. Replacement parts for EDM drill machines: pipe guide, ceramic guide,drill chuck, rubber seal, pipe guide,collect, high press pump, rotational head, motor.
3. EDM tools and related: stainless holder, stainless vise, stainless bridge, super magnet, magnetic chuck, stainless cap screw.
4. EDM consumables: EDM brass wire, EDM brass tube, EDM copper tube, EDM ion exchange resin, EDM moly wire/Molybdenum wire, EDM rust remover,EDM filter.
Advantage of us
* Manufacturer : A leading manufacturer professional to produce wire cut edm wear parts ,supply you
full range WEDM Spare Parts . It is available to make Customized items .
* Quality : Advance production and test equipment, qualify system,experience technology team . All
products is tested one by one before packing and delivery.
* Service : Try our best to satisfy our customers and meet their requirement before sales; The first time
to solve the problems of products after sales.
* History : Near to 8 years of experience on producing WEDM Consumables and Accessories. 4 years of
experience on exporting products to difference counties. Our main market is America,Europe,Asia.
* Product range : Full range edm wear parts,including Charmilles,Agie, Mitsubishi, Fanuc, Sodick,
Chmer, Accutex, Japax, ARD, Brother, ONA , Hitachi, SPM, Makino, Maxi, Seibu,Drilling machine, etc.
Our ShenZhen fair Pictures:
Our EDM Copper Wire production department(All our EDM Copper Wire making machine is full-automic machine)
