Specifications
TUV CE ApprovedScroll Compressor Type
Pure titaniun heat exchanger
japanese compress
R410A Refrigerant
Axen Swimming Pool Heat Pump is one of the most economical systems to heat the swimming pool efficiently. Using the free renewable energy from the air and the earth it delivers up to five times more energy in heating than a traditional heating system such as gas boiler or electric heater. So you will save 4/5 cost of the traditional heating. The unit is working at low running costs, no direct CO2 emission and are able to be integrated with energy systems like solar and boiler. Axen pool heat pump lengthens your swimming season and gives you comfort at high level. You could enjoy swimming pool not only in summer, but also in spring, autumn and even winter time.
| Control panel vailable | Type A type B type C at additional cost | ||||||||||||||
| Titanium heat exchanger |
|
||||||||||||||
| Heating Capacity Air 24 Water 25/27 | W | 15000 | 17000 | 21000 | 24000 | 26000 | 28000 | ||||||||
| BTU | 51000 | 60000 | 73000 | 82000 | 90000 | 95500 | |||||||||
| Heating Input Power | W | 3168 | 3469 | 4250 | 4800 | 5300 | 5600 | ||||||||
| Cooling Capacity | W | 8600 | 10300 | 13500 | 14300 | 16000 | 18000 | ||||||||
| BTU | 48000 | 35200 | 46000 | 4879 | 55000 | 6473 | |||||||||
| Cooling Input Power | W | 2980 | 3600 | 4650 | 4800 | 5730 | 5730 | ||||||||
| Max Current | A | 18.1 | 20.9 | 10.27 | 11.18 | 12.09 | 13 | ||||||||
| Power Supply | V/PH/HZ | 400V/3Ph/50Hz | |||||||||||||
| water temperature range | 15-40 | ||||||||||||||
| Refrigerant | R410A | ||||||||||||||
| Compressor Type | Scroll | ||||||||||||||
| Air to water heat exchanger | Titanium heat exchanger | ||||||||||||||
| Water flow rate | m³/h | 5-8 | 5-8 | 6-10 | 6-12 | 6-12 | 6-13 | ||||||||
| Water Connection | mm | 50 | 50 | 50 | 50 | 50 | 50 | ||||||||
| Dimension | L | mm | 660 | 660 | 660 | 660 | 660 | 810 | |||||||
| W | 660 | 660 | 660 | 660 | 660 | 810 | |||||||||
| H | 860 | 860 | 960 | 960 | 960 | 1050 | |||||||||
| Packing Size | L | mm | 700 | 700 | 700 | 700 | 700 | 950 | |||||||
| W | 740 | 740 | 740 | 740 | 740 | 950 | |||||||||
| H | 1010 | 1010 | 1110 | 1110 | 1110 | 1180 | |||||||||
| Weight | Net Weight | kg | 105 | 108 | 111 | 113 | 113 | 119 | |||||||
| Gross Weight | 113 | 120 | 123 | 125 | 125 | 131 | |||||||||
| Noise | dB(A) | 60 | 60 | 60 | 60 | 60 | 60 | ||||||||
| Heating:Dry bulb 24°C , wet bulb 19°C , inlet water temp 25°C . | |||||||||||||||
| cooling:Dry bulb 35°C , wet bulb 24 °C, outlet water temp 27°C. | |||||||||||||||
Ecological and economical heating
By making use of the renewable energy in the outside air, it consumes much less energy with low carbon emission.
Use environment friendly advanced refrigerant R410a which has no effect on Ozone.
Titanium heat exchanger
Advanced titanium heat exchanger guarantees long life span of heat pump free from corrosion and rust.
Multiple functions:
Cooling & heating function available: Axen heat pump could heat your pool as well as cool the pool.
Auto operation, Auto-restart, Auto defrost
Timer on/off: No human attendance is required
Wide ambient working condition: -5°C to 43°C
Reliable operation
To guarantee the stable running and increase the durability of the unit multiple protection devices have been set into Axen pool heat pump which include insufficient water flow protection, high/low pressure protection, overload protection, compressor protection.
Safe use
Axen pool heat pump works without oil, gas or other hazardous substance which avoid potential risk that goes together. Moreover no gas connection or a fuel tank is needed. No risk of intoxication, smell or pollution from leakage.
Easy installation
Axen pool heat pump is easy to be installed with simple electrical and hydraulic connection. The cost of installation is relatively low.
Self-diagnosis
When there is malfunction Axen pool heat pump will make self diagnosis by displaying error code from the control panel. The problem could be found out at a glance.
Wide application
Axen pool heat pump could ideally suit the pools from 15 to 350m3.
Wide range
Models available 14kw,17kw,21kw,24kw,26kw,28kw.
