90KW Air to water energy-saving high cop brushless dc Swimming pool water heater Heat Pump

Specifications

CE certification pool heat pump
Scroll Compressor Type
Max temp.55c heat pump
R410A Refrigerant heat pump

Axen Swimming  Pool Heat Pump is one of the most economical systems to heat the swimming pool efficiently.  Using the free renewable energy from the air and the earth it delivers up to five times more energy in heating than a traditional heating system such as gas boiler or electric heater.  So you will save 4/5 cost of the traditional heating.   The unit is working at low running costs, no direct CO2 emission and are able to be integrated with energy systems like solar and boiler. Axen pool heat pump lengthens your swimming season and gives you comfort at high level. You could enjoy swimming pool not only in summer, but also in spring, autumn and even winter time.



TECHNICAL DATA		AXSP-48	AXSP-65	AXSP-85	AXSP-120	AXSP-180
Heating Capacity/power input(kw)	A24,W27	4.8/1.07	6.5/1.27	8.3/1.68	12.2/2.36	16.6/3.3
	A24,W22	4.9/0.97	6.6/1.25	8.5/1.66	12/2.15	18/3.58
COP		5.02	5.18	5.12	5.06	5.02
Cooling capacity	KW	3.2	4.5	6.2	9.1
Power Input(H/C)	KW	0.88	1.23	1.73	2.54	3.62
EER		3.62	3.65	3.59	3.58	3.56
Max Current(H/C)	A	6.6	9.2	12.4	18.7	26.2
Power Supply	V/Ph/Hz	220-240/1/50
Water temperature range	°C	15-40
Refrigerant		R410A
Compressor	brand	TOSHIBA	TOSHIBA	TOSHIBA	TOSHIBA	Daikin



Ecological and economical heating

By making use of the renewable energy in the outside air, it consumes much less energy with low carbon emission.

Use environment friendly advanced refrigerant R410a which has no effect on Ozone.

Titanium heat exchanger

Advanced titanium heat exchanger guarantees long life span of heat pump free from corrosion and rust.

Multiple functions:

Cooling & heating function available: Axen heat pump could heat your pool as well as cool the pool.

Auto operation, Auto-restart, Auto defrost

Timer on/off: No human attendance is required

Wide ambient working condition: -5°C to 43°C

Reliable operation

To guarantee the stable running and increase the durability of the unit multiple protection devices have been set into Axen pool heat pump which include insufficient water flow protection, high/low pressure protection, overload protection, compressor protection.

Safe use

Axen pool heat pump works without oil, gas or other hazardous substance which avoid potential risk that goes together. Moreover no gas connection or a fuel tank is needed. No risk of intoxication, smell or pollution from leakage.

Easy installation

Axen pool heat pump is easy to be installed with simple electrical and hydraulic connection. The cost of installation is relatively low.

Self-diagnosis

When there is malfunction Axen pool heat pump will make self diagnosis by displaying error code from the control panel. The problem could be found out at a glance.

Wide application

Axen pool heat pump could ideally suit the pools from 15 to 350m3.

Wide range

Models available 4.5kw, 6.5kw, 8.5kw, 12kw, 18kw, 26kw.
