Suie 15 Inch 5 Wire Touch Screen For Touch Screen Monotor
| General Size | 5.7″ to 23″ |
| Fit in with | Panel display device |
| Mechanical | |
| Input Method | Finger or gloved hand (rubber ,cloth or leather) |
| Active Force | Stylus or Finger or Similar 45g~110g |
| Ball Impact | 13.0. Steel Ball/9g, Height30cm, 1 time, no damage [Impact at center area] |
| Durability | 35 million touches |
| Positional Accuracy | 1.5% |
| Optical | |
| Light Transmission | 85%(Meet ASTM D1003) |
| Clear surface | 3% |
| Antiglare Surface | 4% |
| Anti-Newton | 10% |
| Gloss | 90±20 gloss units tested on a hard-coated front surface Accordance with ASTMD 2457 |
| Electrical | |
| Supply voltage | DC5V |
| Circuit Resistance | X:20~250Ω, Y:20~250Ω (See Figure 1) |
| Linearity | 1.5%, Y1.5% |
| Response | 15ms |
| Insulation | 20MΩ/25V(DC) |
| Resolution | Based on controller resolution of 4096 x 4096 |
| Environmental | |
| OperationTemperature | -40℃ ~ +70℃ |
| Operation Humidity | 20%RH ~ 85%RH, no condensing |
| Storage Temperature | -45℃ ~ +80℃ |
| Storage Humidity | 10%RH ~ 90%RH, no condensing |
| Waterproof | Not damaged by running water applied to the active area |
| Operationg System | |
| Operation System | Linux/ Dos / WinME/95/98 / NT/CE/XP/2000/ win7/Mac OS |
Images
DHL/UPS/Fedex : about 3 ~7working days
EMS/ TNT : 5-10 working days
Hong Kong Post Air Mail/ Hong Kong Post Air Parcel : 7 to 30 days
Notes: Yours goods will be dispatched within 3 business days immediately the payment has been confirmed. If your payment fails, the order will be closed automatically.
2. We are not responsible for any insurance or damage which is caused during shipping. Besides, buyers are responsible for the possible customs duty or tax charged by the local customs officers. Your parcels will be marked with "gift"or "sample"for easy customs clearance. If you want to mark the goods with other item name, or specify an value for customs, please tell us after placing your order.
