Used 350hp workover oil rig for sale

Model

XJ150

Service depth (2-7/8" UE tubing) ft(m)

8530(2600)

Nominal hook load lb(kN)

67440(300)

Max Hook load lb(kN)

131508(585)

Wireline dia/effective line quantity in.(mm)

φ0.87/6(φ22/6)

Max lifting speed of hook ft/s(m/s)

4.6(1.4)

Overall dimensions in traveling condition ft(m)

50.2×8.2×12.7(15.3×2.5×3.87)

Weight lb(kg)

48898(22180)

MODEL

XJ250(40t)

Nominal service depth(ft)(27/8″EUE tubing)

10500

Nominal workover depth (ft)(27/8″DP)

6562

Max. hook load (lbf)

150000

Rated hook load (lbf)

90000

Engine model

T-3A929 or WD615.68

Engine power (hp)

281 or 303

Transmission type

Hydraulic + mechanical

Traveling system

4×3

Effective height of mast (ft)

56

Drilling line diameter (in)

7/8

Hook speed (ft/s)

0.66~4.6

Approaching/departure angle

18°/12°

Min. ground clearance (in)

13

Max. gradient ability

26%

Min. turning diameter (ft)

108

Rotary table model

ZP70

Traveling block model

YG70

Swivel model

SL70

Overall moving dimension (ft)

38×8×13

Main unit mass (lb)

55200
