Shrink Packing Machine

Name: Shrink Packing Machine
Brand: WINMARK
SKU: 109369199
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

WINMARK

Model Number:

YCD

Zhangjiagang Winmark Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name WINMARK

Model Number YCD

Certification ISO9001;CE

After-sales Service Provided Engineers available to service machinery overseas

Driven Type Electric

Condition New

Specifications

1. shrink packing machine
2. for PET bottle or glass bottle
3. with paper support

High speed PE film shrink wrapping machine

Take notice please:

We can provide Pre-sale consultation service, turnkey project and installation running service.

General description

Characteristics

1. Specially designed and manufactured for the high-speed packing reqirements of drinks(pure water ,beverage,juice,and diary product)

2. During the product forward conveying process,it can automatically group the product into package,so as to save time and enhance packing efficiency

3. Touch-screen operating panel with user-friendly interface and convenient parameter setup,absolutely an easy-to-operate machine

4. The ideal model of middle-speed heat-shrinking packager in the domestic market.

Technical parameters

Dimension for the whole unit	L12000mm×W1100mm×H2100mm
Thermal shrinkage passage diemnsion	L2400mm×W650×H450mm
Max.Package Dimension	L600mm×W400mm×H350mm
Packaging Speed	15-21Pcs/min
Transfer Belt Dimension	550mm
Sealing and cut Time/Temperature	0.5-1s 180-260degree centigrade
Operating Power Supply/Power	(TN-S)380V 17KW
Operating Air Pressure	0.6-0.8Mpa
Air Consumption	0.6m³/min
