Specifications
blow injection machine1.HD-32-A1blow injection machine
2.taiwan technique
plastic bottle blow injection machine
Features:
* Screw of big length to diameter ratio, uniform plastication and high plasticizing capability for High Speed PET Bottle Preform Injection Machine
* The High Speed PET Bottle Preform Injection Machine is Multi Step adjustment of injection speed or pressure
* Back pressure control of molten plastic for High Speed PET Bottle Preform Injection Machine
* Double toggle mold closing system with a large force magnification ratio and a large stroke ratio
* Very good speed characteristic of high speed mold closing and low pressure mold protection for High Speed PET Bottle Preform Injection Machine
* The High Speed PET Bottle Preform Injection Machine have Various kinds of hydraulic ejectors
* Double proportional, load sensitive hydraulic circuit
* For big sizes of machines there are several oil pumps in a group, use proportional valve to compensate the difference of pressure or flow between pumps
* Triple interlock of mechanic, electric and hydraulic devices
* Hydraulic knockout core device and rotary mold-parting the work piece device
* Using the computer, electric and hydraulic elements of famous brands in the world
Technical Data:
Item |
Unit |
Data |
||
Max. clamping force |
KN |
3000 |
||
Max. opening force |
mm |
590 |
||
(V×H)Space between tie bars |
mm |
610×610 |
||
(min-max)Mould height |
mm |
220-630 |
||
Max. daylight |
mm |
1220 |
||
Ejector force |
KN |
70.6 |
||
Ejector stroke |
mm |
150 |
||
Ejector quantity |
|
9 |
||
Screw diameter |
mm |
60 |
65 |
70 |
Screw L/D ratio |
L/D |
22.7 |
21 |
19.5 |
Theoretical shot volume |
cm3 |
848 |
995 |
1154 |
Plasticising weight(PS) |
g |
772 |
905 |
1050 |
Injection pressure |
Mpa |
207 |
176 |
152 |
Theoretical injection rate(PS) |
g |
241 |
283 |
328 |
Plasticising capacity(PS) |
g/s |
35.2 |
43.3 |
51.8 |
Screw torque |
N.m |
2530 |
||
Max. screw rotate speed |
r/min |
150 |
||
Injection stroke |
mm |
300 |
||
Pump motor power |
KW |
30 |
||
Pump pressure |
Mpa |
16 |
||
Heating power |
KW |
22 |
||
Heating zone |
|
5 |
||
Size |
m |
6.7×1.75×2.25 |
||
Net weight |
t |
11 |
||
International designation |
|
3000-1750 |
||
Main Buying Procedures--- blow injection machine
Enquiry: contact us by email, phone call, fax, Instant tools (Trademanager, MSN, Skype) and let us know your enquiry.
- Discussion: specify the items you desire, confirm specification; OEM/ODM consultation.
- Quotation: Prices offered and accepted.
- Place order as per contract or discussion.
- Proforma invoice offered to double confirm the order for both-side records.
- Payment settled. Bottle Blowing Machine .
- Order completed under our arrangement.
- Goods shipped as per contracted term.
- Goods arrive at local port or warehouse, depending on contracted term.
