DCGF SERIES BALANCED PRESSURE FILLING 3-IN-1 MONOBLOC

DCGF SERIES BALANCED PRESSURE FILLING 3-IN-1 MONOBLOC photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
WINMARK
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Jiangsu, China
Brand Name WINMARK
Model Number DCGF 16/12/6
Type Other, filling machine, Filling Machine
Power(W) up to the capacity
Certification ISO9001;CE
Warranty ONE YEAR
After-sales Service Provided Engineers available to service machinery overseas

Specifications

soda drink filling machine
1. production capacity: 2000-3000
2.CE certificate
3. PLC control



 soda drink filling machine  carbonated filling machine

 Description

 The series adopts foreign advanced technology and carried out washing, filling and capping in one machine. The entering bottle adopts air force conveying and hanging-type bottle mouth conveying structure. The whole machine adopts frequency control speed, PLC control .the operation and maintenance are convenient and simple. Its characteristics are steady. It is suitable for PET bottle soda drink equipment.

 Parameter

Model:

DCGF16-12-6

Production Capacity:500ml

2000-3000

Suitable Bottle Standard:

round or square shaped bottle.

Polyester Bottle Standard: (mm)

Bottle Diameter:Φ50-Φ110   Bottle Height:150-340

Suitable Cap Standard:

Plastic Screw Cap

Filling Precision: (mm)

≤±5

Filling Pressure:(Mpa)

0.15-0.35

rising Pressure:(Mpa)

0.2-0.25

Motor Power:(kw)

3.5

Overall Size:(mm)

2450×1800×2400

Total Weight: (kg)

3000

About Factory

 15years’ experience in filling line machinery.

About Quality

brand-new equipments with latest design and suitable material made,

About After Sale Service

1 year's warranty period and life time technical support.





Our technology from Taiwan and Germany,Our machine have good quality and competitive price,Hope cooperate with you!
