Help CenterCNC Water Jet Cutting Machine for Aluminum Plate Stainless Steel
Related Products
-
Metal Cutting Machine Max 100mm Thickness XC-30120W Waterjet Cutting MachineUS$ 1,111 - 111,111MOQ: 1 Set -
300mpa/380mpa/400mpa/420mpa Water Jet Cutting MachineUS$ 1,111 - 11,111MOQ: 1 Set
-
CE AND HIGH PRECISSION FOR METAL XC-3080W Waterjet Cutting MachineUS$ 1,111 - 111,111MOQ: 1 Set
-
CE STANDARD AND HIGH PRECISSION XC-3060W Waterjet Cutting Machine PriceUS$ 1,111 - 111,111MOQ: 1 Set
-
Steel, Glass, Granite, Marbel Cutting Machine XC-3050W Waterjet Cutting Machine PriceUS$ 1,111 - 111,111MOQ: 1 Set
Bridge feature:
1.Adopt servo drive configuration Taiwan ball screw,linear guide can achieve seamless movement, to ensure smooth operation. To ensure the smooth transmission of the whole machine.
2.Steel base, beams imported high quality seamless steel pipe, and then empty the true heat treatment, invisible change.
3.A full range of cutting capacity, any plane curve cutting.
4.Specially reinforced bed structure, so that the cutting head does not produce vibration during high-speed operation, the machine runs smoothly, cutting speed, high precision machining.
5.The screw and guide provided by the well-known Taiwan manufacturers, X, Y-axis is the original oil-immersed screw rail lubrication, plus a waterprooof, dust-proof structure to ensure that the machining accuracy of CNC cutting platform, and maximize the service life of the screw guide.
6.Cutting head is equipped with reliable pneumatic high-pressure water switch control device, improve production efficiency.
7.Unique sand valve design, simple structure,the flow of sand smooth, easy to repair.
8.All stainless steel protective cover, dustproof, waterproof, anti-rust, anti-corrosion, easy to use water to clean, maintain the cutting platform perennial burnished as new.
9.4-axis and 5-axis system tilt cutting heading for optional choice with extra charge.
10.Varities kinds of applications:Ceramic, Stone, Glass, Marble, Stainless Steel, Plastic foam, Aluminum
11.any size of cutting machine is availble for our customers requirement.
Item |
high pressure water jet pump |
|
Model |
XC-1325 |
|
Structure |
Bridge |
|
Cutting table size |
2100*1600mm |
|
Stroke |
X-axis |
2000mm |
|
Y-axis |
1500mm |
|
Z-axis |
150mm |
CNC Controller |
Step System / AC Servo System |
|
Accuracy |
±0.1mm |
|
Cutting |
Repeatability |
±0.05mm |
|
Traverse speed |
6500/15000 mm/min |
Power supply |
220V/380VAC,50Hz |
|
Turbocharger parameters | |
Item |
China new model high pressure water jet pump |
Model |
450A |
Maximum pressure |
450Mpa |
Normal operating pressure |
350-380Mpa |
Main motor power |
30KW |
Oil pump |
Variable |
Cooling |
The plate cooling |
High-pressure cylinder |
Imported |
Inlet valve |
Imported |
Ceramic rod |
Imported |
Accumulator |
Single taper |
Power supply |
415/380/220V AC 3P |
