This scheme is including five part, technical parameter, structure of paper making line, equipment of paper making line, equipment of pulp making line and quotation, The detail as follow:
Technical parameter
1. Raw material: waste paper
2. Output paper:Writing paper & Printing paper
3. Output paper weight: 60-80gsm
4. Capacity: 1-2 T/D
5. Working speed: 60-100 m/min
6. Rail space:1300mm
7. Drive way: Alternating current frequency conversion adjustable speed section drive
Structure of paper making line
1. cylinder section: cylinder mould 2 set, Φ1000mm x 1200mm x 1300mm ; couch roller: 2 set, Φ300mm X 1200mm x 1300mm.
2. Press section: Press upper roller(natural granite roll) 1set, φ350×1200×1300mm; bottom press roller(rubber roller), 1set, φ300×1200×1300mm
3. The drying section: Alloy dryer 2 set, Φ1500mm x 1100mm x 1300mm, the hardness of the surface is 210°, including bearing and bearing shell; carrier roller, 1 set, φ300×1200×1300mm, the roller body is cast iron, the surface is wrapped by rubber, the thickness of the rubber is 25mm, the hardness is 95º±2; upper press roller 1 set, φ300×1200×1300mm
4. Winding section: 1092type winding machine 1 set
