Specifications
It is automatic packing the A4 size paper
Output: 18~20pack/min
A4 Photocopy Paper Packaging Machine, Wrapping Machine & Packaging Machine
1. Features and Structure:
1) Multi-functional converter controlled speed regulation by PLC.
2) Man-machine interface touch screen for easy operation.
3) Automatic feeding paper ream.
4) The machine can be used to pack common and printed sheets.
5) Automatic hotmelt glue spraying system.
6) Packaging costs can be greatly reduced, and labour saving.
2. Specification:
Model | DTDP-A4 |
Productive capacity | 18-20(Pcs/min) |
Functions whereby roll overwrap paper can be automatically cross cut and fed | 18-20(Sheets/min) |
Specification of packed object | 210×297×50mm |
Power supply | 380V Three-phase four-wire |
Motor power | 5.1kw |
Gluing power | 3.7kw |
Compressed air | 0.6mpa |
Paper size(Lenght×Width) | 550-560mm×386mm |
Overall dimension | 4800×3050×1450mm |
Weight | 1500kg |
Suitable range | Package material for gluing paper of color printing or hexahedral wrapping |
3. Main component:
Three-gun Automatic Glue Sprayer | 1set | Taiwan |
Touch Screen Control Panel | 1set | Taiwan |
Step Motor | 1set | Sino-foreign joint venture |
Synchronous Motor | 2set | Sino-foreign joint venture |
Paper Cutter | 1set | China |
Inflatable Shaft | 2pcs | China |
Pin-wheel Speed Reducer | 1set | China |
Bearing |
| Imported |
Cylinder | 14pcs | China |
Electric Appliance Module |
| Siemens |
Photoelectricity Proximity Switch |
| Omron |
Qinyang City Friends Machinery Equipment Co.,Ltd located in Qinyang City, Henan province, China, is one of leading paper machine manufacture,which specializes in pulp making machine, paper making machine and paper processing machine manufacturing.
Our company has perfect service system. We have engineer team with rich practice experience, who can supply professional service during the whole deal, including technbology consultation, design factory, project evaluation, detailed design of factory, installation and testing the whole production line, training engineers and workers.
