High Speed 1800mm Culture Paper Machine With Good After-sale Service

High Speed 1800mm Culture Paper Machine With Good After-sale Service photo-1
High Speed 1800mm Culture Paper Machine With Good After-sale Service photo-2
High Speed 1800mm Culture Paper Machine With Good After-sale Service photo-3
High Speed 1800mm Culture Paper Machine With Good After-sale Service photo-4
High Speed 1800mm Culture Paper Machine With Good After-sale Service photo-5
High Speed 1800mm Culture Paper Machine With Good After-sale Service photo-6
US$ 1 - 1,000,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, A4 paper machine
Processing Type:
Printing Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Other, A4 paper machine
Processing Type Printing Machine
Place of Origin Henan, China
Brand Name FRD
Model Number 1800mm
Voltage 380V
Power(W) 5.5KW
Dimension(L*W*H) Depends
Weight 3000kg
Certification CE
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

 High speed 1800mm culture paper machine with good after-sale service

Technical data:

1.Raw material: waste paper, pulp board(wheat straw or sugar cane bagasse are okay )

2.Output paper: culture paper, printing paper, writing paper, etc.

3.Gram weight: 50-100 gsm

4.Capacity: 10 T/D

5.Net paper width: 1800mm

6.Working speed: 120-160 m/min

7.Rail gauge:2700mm

8.Drive way: AC motor adjustable speed, section drive



Main structure of equipment:

1. Fourdrinier part: The length of fourdrinier part is 12m, vacuum couch roll Φ650mm×2300mm open style headbox, inner is bordered with stainless steel, suction box 6 pieces. Roll: none slot roll with rubber covered. Frame: square frame is made of steel.

2. Compression part: Φ700mm×2300mm natural marble stone roller 1 piece, Φ650mm×2300mm rubber roller 1 piece, Φ800mm×3100mm natural marble stone roller 3 pieces, Φ750mm×2300mm rubber roller 3 pieces, rubber hardness HSD 90°±2.

3. Dryer part: Φ1500mm×2300mm alloy dryer can 16 sets. 1 set size press, arrangement: 10+size press+6. Pneumatic load device, rubber hardness HSD 90°±2, multi- dryer part is equipped with fluctuate dryer mesh.

4.Calender and rewinding part: Three rolls calendar and cylinder type winding machine.

5. Driving and controlling part: Equipped with 500 reducer, motors with AC frequency convertor and adjustable speed, processing transmission.

High speed 1800mm culture paper machine with good after-sale service



Raw material

High speed 1800mm culture paper machine with good after-sale service



Paper-making flow charts

High speed 1800mm culture paper machine with good after-sale service



Finished products

High speed 1800mm culture paper machine with good after-sale service

Company Information

Qinyang City Friends Machinery Equipment Co.,Ltd located in Qinyang City, Henan province, China, is one of leading paper machine manufacture,which specializes in pulp making machine, paper making machine and paper processing machine manufacturing.

Our company has perfect service system. We have engineer team with rich practice experience, who can supply professional service during the whole deal, including technbology consultation, design factory, project evaluation, detailed design of factory, installation and testing the whole production line, training engineers and workers.

High speed 1800mm culture paper machine with good after-sale serviceHigh speed 1800mm culture paper machine with good after-sale serviceHigh speed 1800mm culture paper machine with good after-sale serviceHigh speed 1800mm culture paper machine with good after-sale serviceHigh speed 1800mm culture paper machine with good after-sale service

Packaging & Shipping

 High speed 1800mm culture paper machine with good after-sale serviceHigh speed 1800mm culture paper machine with good after-sale serviceHigh speed 1800mm culture paper machine with good after-sale service

Our Services

Hello,this is Crystal!

If you are interested in our paper making machine or you want to know more about our products,please contact with me or by sending me email at any time.

We are willing to establish long-term relationship with new and old customers at home and aboard to achieve mutual benefit.It will be a great honour to serve for you.

High speed 1800mm culture paper machine with good after-sale service

FAQ



Q: Why no person reply to me?
A: Our person is 24hours online. When nobody reply you , please leave your requirements on email or chat tool,we will reply you as soon as possible.
Q: What is guarantee terms ?
A: According to the international practice, performance and mechanical guarantee shall be for 1 year from the successful commissioning or 1.5 years from the date of bill of lading.
Q:Could your engineer can teach and train our workers and stay in our factory for long time?
A:Yes, we have very large engineer installation team. They can train and teach your workers to operate paper machine, but you should pay them salary.





Pre-sales service

1.Help customers find the right product by professional technology andbusiness consultation
2.Provide plans of the machines installation freely
3.Could make customized products according to the clients requirements

4.We will online for 24 hours
After-sales service
1.Fast and saft delivery
2.Assisting our clients to bulid the equipment
3.Training the first-line operators on site
4.Regularly visit clients to solve production problems
