Small Working Area Kraft Paper Machine with ISO Certificate
I. Technical Parameter of the Small Working Area Kraft Paper Machine with ISO Certificate
1.Raw material: waste paper, new pulp
2.Output paper:kraft paper, corrugated paper, kraft liner paper,office paper
3.Output paper weight:90-200 gsm
4.Net paper width: 2400 mm
5.Cylinder width: 3600mm
6.Capacity:20 T/D
7.Drive way: Alternating current frequency conversion adjustable speed ,section drive
II. Main equipment structure of Small Working Area Kraft Paper Machine with ISO Certificate
Cylinder section:stainless steel mesh 4 sets;
Press section: natural marble roll 2 set,rubber roll 2 set, pneumatic pressure device.
Dryer section: alloy dryer can 18 sets,
Sizing section:size roll 2 sets.
Calender section: 2 rolls calender machine . pneumatic pressure device.
Winding section:3200mm model Horizontal pneumatic winding machine 1 set,
Rewinding section: Upper feeding Frame type rewinding machine 1 set.
III. Flow Chart of the Small Working Area Kraft Paper Machine with ISO Certificate
OCC----Chain Conveyor----Hydrapulper----High Consistency Cleaner----Reject Sorter-----double disc refiner----fiber separator---Pressure Screen-----Disc Thickner----Low Consistency Sand Remover----Cylinder Mould----Dryer-----Sizing machine----Kraft Paper Machine-----Paper Rewinder----Finished Paper Roll
