2400mm Multi-cylinder and Multi-wire Kraft Paper Machine for Sale

2400mm Multi-cylinder and Multi-wire Kraft Paper Machine for Sale photo-1
2400mm Multi-cylinder and Multi-wire Kraft Paper Machine for Sale photo-2
2400mm Multi-cylinder and Multi-wire Kraft Paper Machine for Sale photo-3
2400mm Multi-cylinder and Multi-wire Kraft Paper Machine for Sale photo-4
US$ 1 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, corrugated paper machine
Processing Type:
Other, kraft paper machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Other, corrugated paper machine
Processing Type Other, kraft paper machine
Place of Origin Henan, China
Brand Name FRD
Model Number 2400mm
Voltage 380V 50HZ
Certification CE
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description



Technical parameters:

Output paper: kraft paper, corrugated paper, test paper.

Weight : 80-250g/m2

Net paper width: 2400mm

Wire width: 2850mm

Capacity:50T/D

Rail gauge: 3200mm

Drive:  AC converter frequency conversion, adjustable speed

Speed : 80-120m/min



1.1500mm×2850mm,450mm×2850mm38°±2,

Cylinder part: four stainless-steel cylinder moulds

(1500mm×2850mm), five couch rolls(450mm×2850mm),

include one reverse roll(450mm×2850mm), rubber hardness

HS-380±2, pneumatic loading mechanism.

2.600mm×2850mm,550mm×2850mm

Press part : one stone roll(600mm×2850mm),one rubber

roll(550mm×2850mm), a batch of roll doctors, Transmission

part is equipped with one model-500 speed reducer.

3.2500mm×2850mm,1500mm×2850mm

Dryer part: two dry cylinders(2500mm×2850mm) , one touch roll(1500mm×2850mm), pneumatic loading mechanism,

rubber hardness HS- 90º±2.three group of cylinder equipped

with Stem network devices.

2400mm multi-cylinder and multi-wire kraft paper machine for sale



Company Information



Qinyang City Friends Machinery Equipment Co.,Ltd located in Qinyang City, Henan province, China, is one of leading paper machine manufacture,which specializes in pulp making machine, paper making machine and paper processing machine manufacturing.

Our company has perfect service system. We have engineer team with rich practice experience, who can supply professional service during the whole deal, including technbology consultation, design factory, project evaluation, detailed design of factory, installation and testing the whole production line, training engineers and workers.

2400mm multi-cylinder and multi-wire kraft paper machine for sale2400mm multi-cylinder and multi-wire kraft paper machine for sale2400mm multi-cylinder and multi-wire kraft paper machine for sale

Packaging & Shipping

 2400mm multi-cylinder and multi-wire kraft paper machine for sale2400mm multi-cylinder and multi-wire kraft paper machine for sale2400mm multi-cylinder and multi-wire kraft paper machine for sale2400mm multi-cylinder and multi-wire kraft paper machine for sale

Our Services



If you are interested in our machine ,don't hesitate to cantact us,we will provide best price and best service for your buying ,if you have intention to buy,you can consult and contact us directly.

Aslo,our machines are popular with both home and abroad,good in-service,and after-sales,we have make great achievements for our company each year.we will configuate machine under our customers' requirements.we can aslo install and debug machine for you,inlcuidng design the plant,if only our customers need them.

2400mm multi-cylinder and multi-wire kraft paper machine for sale
