Friends 1575mm Multi Cylinder Multi Wire Kraft Paper Making Machine for Jumbo Roll

Friends 1575mm Multi Cylinder Multi Wire Kraft Paper Making Machine for Jumbo Roll photo-1
Friends 1575mm Multi Cylinder Multi Wire Kraft Paper Making Machine for Jumbo Roll photo-2
Friends 1575mm Multi Cylinder Multi Wire Kraft Paper Making Machine for Jumbo Roll photo-3
Friends 1575mm Multi Cylinder Multi Wire Kraft Paper Making Machine for Jumbo Roll photo-4
Friends 1575mm Multi Cylinder Multi Wire Kraft Paper Making Machine for Jumbo Roll photo-5
Friends 1575mm Multi Cylinder Multi Wire Kraft Paper Making Machine for Jumbo Roll photo-6
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, Kraft paper
Processing Type:
Other, Paper making machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Other, Kraft paper
Processing Type Other, Paper making machine
Place of Origin Henan, China
Brand Name FRD
Model Number 1575mm
Voltage 380V
Certification CE
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Friends 1575mm Multi Cylinder Multi Wire Kraft Paper Making Machine for Jumbo Roll

Technical parameter:

1. Raw material: Waste paper

2. Output paper: Corrugated paper, Kraft paper,

3. Output paper weight: 80-300G/M2

4. Net paper width: 2800mm

5. Cylinder mould width: 3400mm

6. Capacity: 15T/D

7. Work speed: 70-170m/min

8. Rail space: 3900mm

9. Drive way: Alternating current frequency conversion adjustable speed

10. Model design: Alloy square frame, two press sections

Main structures:

1. Cylinder part: Φ 1500mm× 3400mm stainless steel cylinder 4 sets, Φ 450mm× 3400mm couch roll 5 sets, reverse roll 1set, Share hardness is 38ºC± 2

2. Press part: Two press sections, Φ 750mm× 3400mm natural marble roller 2 sets, Φ 700mm× 3400mm rubber roll 2 sets, Share hardness is 90ºC± 2, pneumatic pressure device

3. Dryer section: Φ 1500mm× 3400mm alloy dryer 18 sets, 10+8 arrangement. 650 speed reducer 2 sets and 500 speed reducer 1 set.

NO.
Equipment
Quantity(set)
1
2800mm multi-cylinder and multi-mesh paper machine
1
2
dryer can exhaust hood
2
3
axial flow ventilator
3
4
roots pump
2
5
suction box
4
6
2800mm winding machine
1
7
2800mm rewinding machine
1
8
10m 3 horizontal hydrapulper
2
9
2m 2 high frequency vibration screen
4
10
reject separactor
2
11
600 low consistency desander
4
12
20 m 2 vat thicker
2
13
Φ 380mm double disc refiner
8
14
15m conveyer
2
15
Φ 700mmThruster
6
16
4 inch pulp pump
4
17
6 inch pulp pump
8
18
8 inch pulp pump
4
19
frequency conversion controlling cabinet
1
20
Work table
1
21
Air pump
1
22
6T boiler
1
Our Company

Qinyang City Friends Machinery Equipment Co.,Ltd located in Qinyang City, Henan province, China, is one of leading paper machine manufacture,which specializes in pulp making machine, paper making machine and paper processing machine manufacturing.

Our company has perfect service system. We have engineer team with rich practice experience, who can supply professional service during the whole deal, including technbology consultation, design factory, project evaluation, detailed design of factory, installation and testing the whole production line, training engineers and workers.
