1200 Radial Waste Tire Crusher Machine Withhard Alloy Knife Tire Shredding Machine Tire Cutting Tool

1200 Radial Waste Tire Crusher Machine Withhard Alloy Knife Tire Shredding Machine Tire Cutting Tool photo-1
US$ 3,000 - 75,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Reclaimed Rubber Machine
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, Reclaimed Rubber Machine
Place of Origin Shandong, China
Brand Name HUATUO
Model Number ZPS-1200
Voltage CUSTOM MADE
Power(W) 55KW
Dimension(L*W*H) 5405x2400x1800
Weight 13000KG
Certification CE SGS IS9001:2008, CE ,SGS ISO9001:2008 Certificated
Warranty 3 YEARS
After-sales Service Provided Engineers available to service machinery overseas

 1200 Radial waste Tire crusher machine withhard alloy knife tire shredding machine Tire cutting tool



Product Flow



 1200 Radial waste Tire crusher machine withhard alloy knife tire shredding machine Tire cutting tool







1200 Radial waste Tire crusher machine withhard alloy knife tire shredding machine Tire cutting tool1200 Radial waste Tire crusher machine withhard alloy knife tire shredding machine Tire cutting tool1200 Radial waste Tire crusher machine withhard alloy knife tire shredding machine Tire cutting tool1200 Radial waste Tire crusher machine withhard alloy knife tire shredding machine Tire cutting tool1200 Radial waste Tire crusher machine withhard alloy knife tire shredding machine Tire cutting tool





1-Use:

this machine is a special equipment for crushing waste steel wire radial tyre under normal temperature, used for take out the steel wire of tyre in the scope of the size.



2-Characteristic:

this machine has the structure compact, advance technology, low powder consumption, high efficiency, crushing room with off-structure. Easy to maintenance etc. The machine adopting excellent hard alloy steel as it blade, highly hard and wearable is druable; circle mesh screen has grindding structure, dropping pieces with large area is good for the rubber pieces.



Model

zps-900

zps-1200

Input size

Less than 900

Less than 1200

Discharge size

50-300mm(adjustable)

50-300mm(adjustable)

Motor power

30*2kw

75*2kw

Dimension

3450*2100*2400mm

4100*2730*3300mm

Amount of waste tire

0.8-1.5T/h

2000-3800kg/h

Screen power

1.5KW

5.5KW

Main shaft speed

19rpm

22rpm

Screen speed

4rpm

25rpm

Number of blades

18pcs, made of alloy steel, welded

25pcs, made of alloy steel, welded

Gearbox

harden gears, large torque

harden gears, large torque

weight

5.8T

15.6T



Equipped with output conveyor, sharing motor   with screen







Rubber powder application                                                                                   Ø Sports venues

Rubber runway; Recreation ground; Bowling alley;

School stadium;Tennis and basketball courts;Sidewalks

Ø Traffic  Modifying asphalt;  Tire; Speed-down zone; Raft ……

Ø Daily life thing Elastic;  Rubber shoes; Raincoat……

Ø Stationery and sporting goods Eraser; Ping-Pong;  Basketball football……

Ø Construction& building materials

Rubber tiles;  Carpet pad;  Floor ; Roof liner and cover;

Waterproof materials;  Roof and wall waterproofing membrane……

Ø  Industrial products
Reclaimed rubber;  Triangular belt;  Gasket ring;  Hose;  Conveyer belt……

 1200 Radial waste Tire crusher machine withhard alloy knife tire shredding machine Tire cutting tool1200 Radial waste Tire crusher machine withhard alloy knife tire shredding machine Tire cutting tool1200 Radial waste Tire crusher machine withhard alloy knife tire shredding machine Tire cutting tool1200 Radial waste Tire crusher machine withhard alloy knife tire shredding machine Tire cutting tool
