reflective Sensor EX-L221 world smallest Amplifier Built-in Ultra-compact Laser Sensor

Specifications

reflective Sensor EX-L221 world smallest Amplifier Built-in Ultra-compact Laser Sensor
Spot reflective type

reflective Sensor EX-L221 world smallest Amplifier Built-in Ultra-compact Laser Sensor Spot reflective type Built-in amplifier in this size! Introducing world smallest* Amplifier Built-in Laser Sensor (* Based on research conducted by Panasonic Electric Works SUNX as of

September 2010) Sensing range 45 to 300 mm 1.772 to 11.811 in (for non-gloss white paper 100 x 100mm 3.937 x 3.937 in) Emission spot size (Typical) dia. 1 mm dia. 0.039 in or less (at a sensing distance of 300 mm 11.811 in) Sensing object Opaque, translucent or transparent object Minimum sensing object (Typical) Gold wire of dia. 0.01 mm dia. 0.0004 in Hysteresis 20 % or less of operation distance Repeatability Perpendicular to sensing axis: 0.05 mm 0.0020 in or less Repeatability (Typical)(perpendicular to sensing axis) 0.02 mm 0.0008 in or less(at 100 to 200 mm 3.937 to 7.874 in sensing distance) Supply voltage 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less Current consumption 15 mA or less Output NPN open-collector transistor - Maximum sink current: 50 mA - Applied voltage: 26.4 V DC or less (between output and 0 V) - Residual voltage: 2 V or less (at 50 mA sink current), 1 V or less (at 16 mA sink current) Output:Output operation Light-ON / Dark-ON selectable by the output operation switching input Output:Short-circuit protection Incorporated (short-circuit protection / inverse polarity protection) Response time 0.5 ms or less Interference prevention function Incorporated (Two sensors can be mounted close together.) Sensitivity adjuster Continuously variable adjuster Protection IP67 (IEC) Ambient temperature -10 to +55 degrees +14 to +131 degrees Fahrenheit (No dew condensation or no icing condition), Storage: -30 to +70 degrees -22 to +158 degrees Fahrenheit lasor sensor models: EX-L211; EX-L211-P; EX-L212; EX-L212-P; EX-L221; EX-L221-P; EX-L261; EX-L261-P; EX-L262; EX-L262-P; EX-L291; EX-L291-P;  Standard type M8 pigtailed type EX-L261; EX-L261-J; EX-L261-P; EX-L261-P-J; EX-L262; EX-L262-J; EX-L262-P; EX-L262-P-J; EX-L211; EX-L211-J; EX-L211-P; EX-L211-P-J; EX-L212; EX-L212-J; EX-L212-P; EX-L212-P-J; EX-L291; EX-L291-J; EX-L291-P; EX-L291-P-J; EX-L221; EX-L221-J; EX-L221-P; EX-L221-P-J; 5 m 16.404 ft cable length type EX-L261-C5; EX-L261-P-C5; EX-L262-C5; EX-L262-P-C5; EX-L211-C5; EX-L211-P-C5; EX-L212-C5; EX-L212-P-C5; EX-L291-C5; EX-L291-P-C5; EX-L221-P-C5;
