Small switch joysticks miniature APEM Switches Compact size joystick switch

Specifications

Small switch joysticks miniature APEM Switches Compact size joystick switch
a versatile range of low cost switch joysticks

Small switch joysticks miniature APEM Switches Compact size joystick switch
a versatile range of low cost switch joysticks
ideal for light to medium duty environments where proportional control is not a necessity.
Configurable with either single or double pole switching,
specified as screw or bush mounted.
two construction options,V3 or V4 switches.
   V4 switches may be specified with 6A or 10A operation,
   V3 switches :up to 16A operation.

Compact size:
Robust construction
Single or dual axes
Single or double pole
Gold contacts
Bushing or screw mount
V4 switches; V3 switches
Alternative handle selection: including pushbutton handles
Mechanical Life – >5 Million Operations
Lever Travel – 24? (12? from center)
Lever Material – Stainless Steel or Brass
Mass/weight – 40g
Body Material – Mineral Filled Nylon-6
Handle Material – See
Boot Material – Neoprene
Mounting - Screw – 4 x M2.5 Stainless (Slotted)
Mounting - Bush – Single Point 22mm Diameter

Number of Switches – 2, 4, or 8
Nominal Current – 6A, 10A, or 16A
Maximum Voltage – 250V AC
Contacts #1 6A - V4 – Gold
Contacts #2 10A - V4 – Silver
Contacts #3 16A - V3 – Silver
Contacts #4 Right Angle – Silver
Contacts #5 Faston Style - V4 – Silver
Contacts #6 Faston Style - V3 – Silver
Contacts #7 – Silver
Switch Contacts – Changeover
Contact Life – Load Dependent
Pushbutton Cable – Blue
Temperature Range – -20oC to 50oC
Above Panel Seal (IP) – To IP67
