Specifications

VDE approval SOLID STATE RELAY HA6050 Crydom relay
Ratings from 25A to 125A @ 48-660 VAC
SCR output for heavy industrial loads

VDE approval SOLID STATE RELAY HA6050 Crydom relay
Ratings from 25A to 125A @ 48-660 VAC
SCR output for heavy industrial loads
AC or DC control
Zero-crossing (resistive loads) or random-fire (inductive loads) output
Low Leakage (Snubberless)
Control Voltage 25A 50A     90A     125A
3-32 VDC  HD6025  HD6050    HD6090  HD60125
90-280 Vrms HA6025 HA6050   HA6090 HA60125
18-36 Vrms HA6025E HA6050E  HA6090E HA60125E
HA6025,90-280 VAC,25 Amps,48-660 VAC
HA6025-10, 90-280 VAC, 25 Amps, 48-660 VAC
HA6025E, 18-36 VAC, 25 Amps, 48-660 VAC
HA6025E-10, 18-36 VAC, 25 Amps, 48-660 VAC
HA6050, 90-280 VAC, 50 Amps, 48-660 VAC
HA6050-10, 90-280 VAC, 50 Amps, 48-660 VAC
HA6050E, 18-36 VAC, 50 Amps, 48-660 VAC
HA6050E-10, 18-36 VAC, 50 Amps, 8-660 VAC
HA6090, 90-280 VAC, 90 Amps, 48-660 VAC
HA6090-10, 90-280 VAC, 90 Amps, 48-660 VAC
HA6090E, 18-36 VAC, 90 Amps, 48-660 VAC
HA6090E-10, 18-36 VAC, 90 Amps, 48-660 VAC
HA60125, 90-280 VAC, 125 Amps, 48-660 VAC
HA60125-10, 90-280 VAC, 125 Amps, 48-660 VAC
HA60125E, 18-36 VAC, 125 Amps, 48-660 VAC
HA60125E-10, 18-36 VAC, 125 Amps, 48-660 VAC
