HG Hand Grip Hall Effect Joysticks Apem Components CH PRODUCTS

Specifications

HG Hand grip Hall effect joysticks Apem Components CH PRODUCTS
rugged Hall effect controller
high operating force, hand-operated
reliable positioning control.
High-function handles.
single,dual or triple axes,
custom configured for harsh applications.
Typical applications include military vehicles,
refuse handling trucks, as well as fire and offhighway
vehicles.
Rugged, hand operation
Hall effect sensing
Sealed up to IP68
10 million life cycles
Redundant output available
Analog, CANbus, USB and custom outputs available
Mechanical Angle of Movement – 38
Expected Life – 10 million cycles
Sensor – Hall effect
Resolution – Infinite
Supply Voltage Operating – 5.00VDC
Reverse Polarity Max – -14.5VDC
Overvoltage Max – 18VDC
Output Voltage – 0.34V - 4.65V
Output Impedance – 6Ω
Current Consumption Max – 10mA max per axis
Return to Center Voltage (No Load) – ±200mV
Operating Temperature – -25oC to 70oC (-13oF to 158oF)
Storage Temperature – -40oC to 70oC (-40oF to 158oF)
Sealing – IP65 to IP68
EMC Immunity Level (V/M) – IEC 61000-4-8:2009
EMC Emissions Level – IEC 61000-4-3:2006
ESD – IEC 61000-4-2:2008
CANbus OUTPUT VERSION
Supply Voltage Range – 6V to 40V
CANbus Version – J1939
Hand grip models:
HG-100IR000-U; HG-210IR000-U;
HG-220IR000-U; HG-330IR000-U;
HG-430IR000-U; HG-340IR000-U;
HG-440IR000-U; HG-2X0IR000-U;
HG-2Z0IR000-U;

HG-100IS000-U; HG-210IS000-U;
HG-220IS000-U; HG-330IS000-U;
HG-430IS000-U; HG-340IS000-U;
HG-440IS000-U; HG-2X0IS000-U;
HG-2Z0IR000-U;
