Specifications
Konics pressure transmitter model KT-302H Gauge Pressure Transmitter KT-301 Korea Absolute Pressure TransmitterChina Beijing
Konics pressure transmitter model KT-302H Gauge Pressure Transmitter KT-301 Korea Absolute Pressure Transmitter
China Beijing Shenzhen Wuxi Konics pressure sensor
KT-302H with HART-protocol
KT-302HS KT-302HA suitable for various sensors
converts input signals into 4 to 20 mA analogue output signal.
Standard installation of the KT-302H is for KT-301 housing.
It is able to measure up to 0.2kg/cm2G ~ 350kg/cm2G
with a variety auxiliary functions and explosion proof structure
and set transmitter parameter and be remote monitoring.
Continuously rotatable display (330°)
Popular sensors acceptable
Self stability and filter setup
Excellent EMC performance
* Range reduce : 3:1
* Measuring cycle : 500ms
* CMRR : 140dB
* NMRR : 40dB
* Output: 4~20mA DC
* Power supply : 15~35VDC
* Over pressure : 300% of max. span (URL)
* Accuracy : ±0.3% of Span for Span
* Stability
- Range 01 : ±0.2% of URL for 6 months
- Range 02~05 : ±0.1% of URL for 6 months
* Isolation : 1000VAC 1minute(Line to Ground)
* Responding time : 1sec
* Degree of protection : IP65(ExdⅡ CT6)
* Indicator : 4Digit LCD
* Material of case : Body (Aluminum) Cover O-Ring (Buna N)
* Weight : 2.3kg(Body)
