Specifications
Korea Konics pressure transmitter TPS20 High-Reliability Pressure Transmitter TPS20GTPS20A electric pressure transmitter
Korea Konics pressure transmitter TPS20 High-Reliability Pressure Transmitter TPS20G
TPS20A electric pressure transmitter adopts stainless steel diaphragm for pressure part.
enables to measure up to 0.2~350 kgf/cm2 with high accuracy and reliability.
China Beijing Shenzhen Wuxi
High-accuracy, high-reliability simple pressure transmitter by adoption of Stainless Steel Diaphragm
Pressure transmitter TPS20 series, adopted stainless steel diaphragm, are highly precise and reliable.
It measures a wide range of pressure scale.
The most reliable & stable performance and wide choices will satisfy with your requirements at any place you need.
* Measuring for pressure of air, water, oil, etc.
* A variety of model depending on field (Head Type, Din Connector Type, Connector Cable Type)
* Stainless Steel Diaphragm adopted for temperature characteristics
* DC 4-20mA transmission output by 2-wire
<Specifications>
* Measuring range : -760mmHg ~ 0 to 30kg/cm2A, 0~0.2 to 350kg/cm2G , 0~1.0 to 30kg/cm2Abs
* Allowable over pressure : 300% of max. span
* Power supply : 15V ~ 35VDC
* Output : 4~20mA DC
* Load resistance : Max. 600Ω
* Power consumption : 0.5W
* Accuracy : ±0.3% F.S(Including Linearity, Hysteresis, Repeatability)
* Temperature characteristic
- ZERO : ±0.03% F.S
- SPAN : ±0.03% F.S(25°C STD)
* Weight : Approx. 320g (Head type STD)
