Specifications
MP5W Autonics pulse meter MP5M Rate meter MP5W-4N MP5S MP5Yauthorized Autonics distributor
digital pulse meter MP5S MP5Y MP5W
MP5W Autonics pulse meter MP5M Rate meter MP5W-4N MP5S MP5Y
authorized Autonics distributor
digital pulse meter
MP5S 48x48mm
MP5Y 72x36mm
MP5W 96x48mm
MP5M 72x72mm
supports 13 kinds of operation modes to measure various industrial numerical data
including Frequency, Absolute ratio, Passing time and Error ratio.
Having diverse functions with various output types,
the series could be widely used in any industrial fields.
50kHz of high speed response time
*13 kinds of various operation modes :
Revolution, Speed, Frequency, Absolute ratio, Passing time,
Error ratio, Period, Density, Passing speed, Error,
Time width, Length measurement, Interval, Integration,
Multiplication(MP5M have 11 operation modes)
*Various output function :
Relay output, NPN/PNP open collector output,
Low speed serial output, BCD output,
PV transmission, RS485 communication output
*Various functions :
Prescale function, Data monitoring function, Hysteresis
width setting function, Max./Min. value monitoring
function, Delay function, Auto zero time setting function,
Lock setting function, Delay of display period function
*Max. display range : -19999 ~ 99999(MP5M:0~99999)
*Various display units : rpm, rps, Hz, kHz, sec, min, m, mm, mm/s, m/s,
m/min, m/h, ?/s, ?/min, ?/h, %, counts, etc.
*Selectable voltage input(PNP) or No voltage input(NPN)
*50kHz High speed response function
