Energy saving Reliable quality natural gas generator set 500kw by advanced technology
1. Main technical specification of natural gas generator set 500kw
Model of generating sets | SP500GFT |
Model of engine | G12V190ZLDT-2 |
Rated power KW | 500 |
Rated speed r/min. | 1200 |
Rated voltage V | 440/254 |
Rated frequency Hz | 60 |
Rated power factor | 0.8 |
CH4 Requirement | ≥70% |
H2S Requirement | ≤15ppm |
Gas pressure | ≥7kpa |
Gas consumption | 0.29~0.32Nm3/kw.h |
Supply method | 3 phases 4 lines |
Excitation method | brushless |
Starting method | 24V DC starter or 24V |
Cooling method | Closed cooling water |
Speed modulate method | Electronic control |
Net weight kg | 13800 |
Overall dimension L×B×H(mm) | 6200×2330×2776.5 |
2. Main electrical performance data
Voltage | Stable regulating rate | ±2.5% |
Instantaneous regulating rate | ≤±20% | |
Recovery time | ≤2s | |
Fluctuation | ≤1% | |
Frequency | Stable regulating rate | 0~5% |
Instantaneous regulating rate | ≤±10% | |
Recovery time | 7s | |
Fluctuation | ≤1% |
3. Main technical data of engine
Model of engine | G12V190ZLDT-2 |
Rated power/speed | 600KW/1200rpm |
Model of control system | EGS-02 (WOODWARD COMPANY) |
Overall dimension L×B×H(mm) | 2785×1628×2437 |
Net weight | 5300kg |
Specific heat consumption | ≤11000KJ/KW.h |
Specific oil consumption | ≤1.6g/KW.h |
H2O | no liquid state water vapour in natural gas |
Number and layout of cylinders | 12, 60° V |
Type | Four stroke, water cooled, turbocharged and aftercooled, spark plug ignition |
Bore | 190mm |
Stroke | 210mm |
Total displacement | 71.45L |
Compression ratio | 12:1 |
Direction of rotation (facing to end) | Counter-Clockwise |
Lubricating method | Pressure and splash lubrication |
details photo for natural gas generator set 500kw
A. Supermaly advantage:
1. Professional diesel generator manufacturer, not trader
2. Decades’ years of manufacturing and exporting experience
3. Adopt International quality standards, to meet high quality requirement
4. Good reputation for Reliable quality & Reasonable price
5. Strong technical support ,quality checking strictly and 24hrs service team
6. Advanced production line with skilled workers
7.Some in stock and quick delivery
8.Choosing the reliable quality and famous brand for each parts
B. Supermaly Certificate:
C. Supermaly exhibition all over the world:
We attend the Canton fair in April and Oct each year.We also attend different countries fair with our generator.For details pls contact us online or by email.
Warranty policy
Guarantee for one year or 1500 hours whichever reach first from ex-factory date.
During the guarantee period, we will provide the free easy-damageable
spare parts of diesel engine caused by our quality of production or raw material.
After expiration, we provides cost spare parts maintenance of gensets
